FIP-400 Fiber Inspection Probe
ORDERING INFORMATION
Model
FIP-400-P- SINGLE = Video inspection probe
Single magnification
FIP-400-P- DUAL = Video inspection probe
Dual magnification
FIP-400-D = Handheld display
FIP-400-USB 1 = USB1 converter with software,
compatible with FTB-400 and IQS-500
FIP-400-USB 2 = USB2 converter with software for PC e ,
FTB-500 d and IQS-600
FIP-400-USB
FIP-400- XX - XX
Example: FIP-400-P-SINGLE-FIPT-400-LX5-APC
Extra Adapter Tips d
00 = Without extra FIP-400 tip
FIPT-400- LC-K
FIPT-400- 25A-K
FIPT-400- ADAPTER = Adapter tip
FIPT-400- D4 = D4 tip for bulkhead adapter
FIPT-400- E2000 = E-2000 tip for bulkhead adapter
FIPT-400- E2000-APC = E2000 APC tip for bulkhead adapter
FIPT-400- FC-SC-A6 = FC and SC angled tip for bulkhead (60 degree)
FIPT-400- FC-SC-APC = FC APC angled tip for bulkhead adapter
FIPT-400- LC = LC tip for bulkhead adapter
FIPT-400- LC-A6 = LC angled tip for bulkhead adapter (60 degree)
FIPT-400- LC-APC = LC/APC tip for bulkhead adapter
FIPT-400- LEMO = LEMO tip for bulkhead adapter
FIPT-400- LX5-APC = LX.5/APC tip for bulkhead adapter
FIPT-400- MTP2 = MTP2 tip for bulkhead adapter (extended, reversible)
FIPT-400- MTP2-K = MTP, APC and UPC tips for bulkhead adapter (extended, reversible)
FIPT-400- MTPA-TIP = MTPA replaceable nozzle for MTP2 (extended, reversible)
FIPT-400- MTPA2 = MTP/APC tip for bulkhead adapter (extended, reversible)
FIPT-400- MTP2-TIP = MTP2 replaceable nozzle for MTP2 (extended, reversible)
FIPT-400- MU = MU tip for bulkhead adapter
FIPT-400- MU-L = MU tip for bulkhead adapter (extended)
FIPT-400- ODC-S = ODC Socket (male) tip
FIPT-400- ODC-U = ODC Universal Guide tip
FIPT-400- ODC-2PIN-P = ODC 2 Pin Plug (female) Guide tip
FIPT-400- ODC-4PIN-P = ODC 4 Pin Plug (female) Guide tip
FIPT-400- ODC-2PIN-P-K = ODC 2 Pin Plug (female) Guide & Universal tip
FIPT-400- ODC-4PIN-P-K = ODC 4 Pin Plug (female) Guide & Universal tip
FIPT-400- ODC-2&4PIN-P-K = ODC 2 & 4 Pin Plug (female) Guides & Universal tip
FIPT-400- SC-APC = SC APC tip for bulkhead adapter
FIPT-400- OTAP-APC = OptiTap™ bulkhead adapter
FIPT-400- OTIP-MT-APC = MT/APC type OptiTip™ for male and female connectors
FIPT400- OTIP-MT-APC/M = Male adapter tube for FIPT-400-OTIP-MT-APC tip
FIPT-400- SC-L = SC tip for bulkhead adapter (extended)
FIPT-400- ST = ST tip for bulkhead adapter
FIPT-400- U12M = Universal patchcord tip for 1.25 mm ferrule
FIPT-400- U12MA = Universal patchcord tip for 1.25mm APC ferrule
FIPT-400- U20M2 = Universal patchcord tip for 2.0 mm ferrule (P4, LEMO)
FIPT-400- U25MA = Universal patchcord tip for 2.5 mm APC ferrule
Notes
a. Dual model only
b. Works with USB 2.0 adapter, FOT-930 and FTB-200
c. Without battery
d. FTB-500 minimum Toolbox software requirement: 6.28 or higher
e. May require USB1 or USB2 depending on user’s PC
