BRT-320A
Optical Return Loss Test Set
SPBRT320A.6AN © 2006 EXFO Electro-Optical Engineering Inc. All rights reserved. Printed in Canada 06/08
ORDERING INFORMATION
NOTES
a. Characterized at 23 °C ± 2 °C (70 °F ± to 77 °F).
b. rms = root mean square.
c. Typical, after 5-minute warmup (measurement mode activated only after warmup).
d. Typical, after a 15 minute warmup.
e. For temperatures ranging from —10 °C to 40 °C (14 °F to 104 °F).
f. From 0 dB to —30 dB.
g. For reflection measurements from —15 dB to —50 dB.
Connector on measurement port must cause less than —50 dB of reflection
to maintain resolution.
h. Typical.
BRT-320A- XX BLC- XX
SPECIFICATIONS a
Model BRT-320A-02BLC-58 BRT-320A-03BLC-58 BRT-320A-23BLC-58 BRT-320A-04BLC BRT-320A-34BLC
Wavelength (nm) 1310 ± 15 1550 ± 15 1310/1550 ± 15 1625 ± 15 1550/1625 ± 15
Spectral width (rms) b (nm) < 5 < 5 < 5 < 5 < 5
Output power stability (dB)
15 minutes c ± 0.01 ± 0.01 ± 0.02 — —
1 hour d ± 0.05 ± 0.05 ± 0.06 — —
Temperature stability e (dB) ± 0.2 ± 0.2 ± 0.3 — —
Reflection range (dB) 0 to —70 0 to —70 0 to —70 0 to —70 0 to —70
Display resolution f (dB) 0.01 0.01 0.01 0.01 0.01
Linearity g (dB) ± 0.1 ± 0.1 ± 0.1 ± 0.1 ± 0.1
Uncertainty (accuracy) g (dB) ± 0.5 ± 0.5 ± 0.5 ± 0.5 ± 0.5
Minimum output power (dBm) —6.5 —6.5 —7.5 —3 —9/—7
Polarization sensitivity h (dB) ± 0.15 ± 0.15 ± 0.15 ± 0.15 ± 0.15
GENERAL SPECIFICATIONS a
STANDARD ACCESSORIES
SAFETY
Size (H x W x D) 21 cm x 11 cm x 5 cm (8 3 / 4 in x 4 1 / 2 in x 2 in)
Weight unit 0.8 kg (1 3 / 4 lb)
shipping 2.5 kg (5 1 / 2 lb)
Temperature operating —10 °C to 40 °C (14 °F to 104 °F)
storage —30 °C to 60 °C (—22 °F to 140 °F)
Relative humidity 0 % to 95 % non-condensing
Power Built-in NiCd batteries (10 hours of operation), 9 V alkaline battery backup, AC adapter/charger
EXFO Corporate Headquarters > 400 Godin Avenue, Quebec City (Quebec) G1M 2K2 CANADA Tel.: 1 418 683-0211 Fax: 1 418 683-2170 [email protected]
Toll-free: 1 800 663-3936 (USA and Canada) www.EXFO.com
EXFO is certified ISO 9001 and attests to the quality of these products.
This device complies with Part 15 of the FCC Rules. Operation is
subject to the following two conditions: (1) this device may not cause
harmful interference, and (2) this device must accept any interference
received, including interference that may cause undesired operation.
EXFO has made every effort to ensure that the information contained
in this specification sheet is accurate. All of EXFO’s manufactured
products are compliant with the European Union’s WEEE directive. For
more information, please visit www.EXFO.com/recycle. However, we
accept no responsibility for any errors or omissions, and we reserve the
right to modify design, characteristics and products at any time without
obligation. Units of measurement in this document conform to SI
standards and practices. Contact EXFO for prices and availability or to
obtain the phone number of your local EXFO distributor.
For the most recent version of this spec sheet, please go to the EXFO
website at http://www.EXFO.com/specs
In case of discrepancy, the Web version takes precedence over any printed
literature.
EXFO Montreal 2650 Marie-Curie St-Laurent (Quebec) H4S 2C3 CANADA Tel.: 1 514 856-2222 Fax: 1 514 856-2232
EXFO Toronto 160 Drumlin Circle Concord (Ontario) L4K 3E5 CANADA Tel.: 1 905 738-3741 Fax: 1 905 738-3712
EXFO America 3701 Plano Parkway, Suite 160 Plano, TX 75075 USA Tel.: 1 800 663-3936 Fax: 1 972 836-0164
EXFO Europe SOUTHAMPTON > Omega Enterprise Park, Electron Way Chandlers Ford, Hampshire S053 4SE ENGLAND Tel.: +44 2380 246810 Fax: +44 2380 246801
EXFO Asia 151 Chin Swee Road, #03-29 Manhattan House SINGAPORE 169876 Tel.: +65 6333 8241 Fax: +65 6333 8242
EXFO China No.88 Fuhua, First Road Shenzhen 518048, CHINA Tel.: +86 (755) 8203 2300 Fax: +86 (755) 8203 2306
Central Tower, Room 801, Futian District
Beijing New Century Hotel Office Tower, Room 1754-1755
Beijing 100044 P. R. CHINA Tel.: +86 (10) 6849 2738 Fax: +86 (10) 6849 2662
No. 6 Southern Capital Gym Road
Find out more about EXFO's extensive line of high-performance portable instruments by visiting our website at www.EXFO.com.
Source code
02BLC = 1310 nm TEC laser
03BLC = 1550 nm TEC laser
23BLC = 1310/1550 nm TEC laser
04BLC = 1625 nm TEC laser
34BLC = 1550/1625 TEC nm laser
Connector code
EA-EUI-28 = APC/DIN 47256
EA-EUI-89 = APC/FC narrow key
EA-EUI-91 = APC/SC
EA-EUI-95 = APC/E-2000
With EA, a standard test jumper is provided:
EUI-28 = TJ-B86-86
EUI-89 = TJ-B58-58
EUI-91 = TJ-B88-88
EUI-95 = TJ-B96-96
Example: BRT-320A-02BLC-EA-EUI-89
User Guide, AC adapter/charger, NiCd batteries, 9 V alkaline
battery, carrying case, protective holster, shoulder strap, mandrel
tool, complimentary test jumper, and Certificate of Compliance.
This product complies with 21 CFR 1040.10 and IEC 60825-1:
Ed 1.1 1998:
CLASS 1 LASER PRODUCT
