15
JD788A CELLADVISOR SIGNAL ANALYZER
Optional Optical Power Sensors
MP-60 Miniature USB 2.0 Optical Power Sensor
Wavelength Range: 780 to 1650 nm
1300, 1310, 1490, 1550 nm: –50 to +10 dBm
850 nm: –45 to +10 dBm
MP-80 Miniature USB 2.0 Optical Power Sensor
Wavelength range: 780 to 1650 nm
1300, 1550 nm: –35 to +23 dBm
850 nm: –30 to +23 dBm
Optional RF Adapters
G710050570 Adapter Type-N(f) to Type-N(f), DC to 6 GHz, 50 Ω
G710050571 Adapter Type-N(m) to DIN(f), DC to 4 GHz, 50 Ω
G710050572 Adapter DIN(m) to DIN(m), DC to 4 GHz, 50 Ω
G710050573 Adapter Type-N(m) to SMA(f), DC to 18 GHz, 50 Ω
G710050574 Adapter Type-N(m) to BNC(f), DC to 1.5 GHz, 50 Ω
G710050576 Adapter Type-N(m) to DIN(m), DC to 4 GHz, 50 Ω
G710050577 Adapter Type-N(f) to DIN(f), DC to 4 GHz, 50 Ω
G710050578 Adapter Type-N(f) to DIN(m), DC to 4 GHz, 50 Ω
G710050579 Adapter DIN(f) to DIN(f), DC to 4 GHz, 50 Ω
Optional Miscellaneous
G710050581 Attenuator 40 dB, 100 W, DC to 4 GHz
(unidirectional)
JD74050341 Soft carrying case
JD71050342 Hard carrying case
JD74050343 Backpack carrying case
G710050585 RF directional coupler, 700 MHz to 4 GHz, 30 dB,
input/output; Type-N(m) to Type-N(f), tap off;
Type-N(f)
9
G710050586 RF Combiner, 700 MHz to 4 GHz, Type-N(f) to
Type-N(m)
9
G710550324 External battery charger
JD780A362 JD780A series user’s manual – printed version
9. Highly recommended for LTe testing.
Ordering Information (cont'd)
