FTB-200 Compact Platform
SPECIFICATIONS a
Display Touchscreen, color, 640 x 480 TFT 163 mm (6.5 in)
Interfaces Two USB 2.0 ports
RJ-45 LAN 10/100/1000 Mbit/s
Fiber inspection probe connector port (video)
Built-in Bluetooth and Wi-Fi (hardware option)
Storage 8 GB internal memory (flash)
Battery
Rechargeable lithium-ion batteries
8 hours of operation as per Telcordia (Bellcore) GR-196
Power supply
AC/DC adapter, input 100-240 VAC, 50-60 Hz,
1.6 A max, output: 24 VDC, 90 W
Computer
Intel ATOM processor
Windows Embedded Standard
GENERAL SPECIFICATIONS
Temperature
Operating
Storage
b
0 °C to 50 °C (32 °F to 122 °F)
–40 °C to 60 °C (–40 °F to 140 °F)
Relative humidity 0 % to 95 % non-condensing
Size (H x W x D) 322 mm x 197 mm x 109 mm
(12
11 /
16
in x 7 ¾ in x 4 5 /
16
in)
Weight b 2.1 kg (4.6 lb)
Vibration <1.5 g at 10 Hz to 500 Hz (on three main axes)
Mechanical shock <760 mm on six sides and eight main edges
(compliant to GR-196-CORE)
VISUAL FAULT LOCATOR (VFL) (OPTIONAL)
Laser, 650 nm ±10 nm
CW
Typical P
out
in 62.5/125 µm: 3 dBm (2 mW)
ACCESSORIES
FP4S 400x Fiber Inspection Probe GP-2028 Computer security cable kit
FP4D 200x/400x Fiber Inspection Probe GP-2112 3G Universal USB Dongle
GP-10-070 Rigid FTB-200 carrying case GP-2113 GPS USB Dongle
GP-10-072 Semi-rigid FTB-200 carrying case GP-2116 Single-slot storage module
GP-302 USB mouse GP-2137 USB-to-RS-232 converter
GP-1002 Headset GP-2138 DC car adapter/inverter
GP-1008 VFL adapter (2.5 mm to 1.25 mm) GP-2144 USB 16G micro-drive
GP-2001 USB keyboard GP-2155 Carry-on size backpack c
GP-2016 10 feet RJ-45 LAN cable
PM-200 BUILT-IN POWER METER SPECIFICATIONS d
Calibrated wavelengths (nm) 850, 1300, 1310, 1490, 1550, 1625, 1650
Optional CWDM calibrated
wavelengths (nm) 1270, 1290, 1310, 1330, 1350, 1370, 1390, 1410, 1430, 1450, 1470, 1490,
1510, 1530, 1550, 1570, 1590, 1610, 1383, 1625
Power range (dBm) 10 to —86 (InGaAs)
26 to —64 (GeX)
Uncertainty (%) e ±5 % ± 3 pW (InGaAs)
±5 % ± 0.4 nW (GeX)
Display resolution (dB)
InGaAs
GeX
0.01 = max to —76 dBm
0.1 = —76 dBm to —86 dBm
1 = —86 dBm to min
0.01 = max to —54 dBm
0.1 = —54 dBm to —64 dBm
1 = —64 dBm to min
Automatic offset nulling range f Max power to —63 dBm for InGaAs
Max power to —40 dBm for GeX
Tone detection (Hz) 270/1000/2000
LASER SAFETY
21 CFR 1040.10 AND IEC 60825-1:2007
CLASS 3R WITH VFL OPTION
Notes
a. All specifications valid at 23
o C (73 o F).
b. Not including internal batteries. Battery maximum storage temperature: 60 o C (140 o F).
c. The selected model may change without notice.
d. At 23 ºC ± 1 ºC, 1550 nm and FC connector. With modules in idle mode. Battery operated.
e. Up to 5 dBm.
f. For ±0.05 dB, from 18 ºC to 28 ºC.
This product complies with 21 CFR 1040.10 and
1040.11 except for deviations pursuant to Laser
Notice No.50 dated 2001.
If VFL option is available
LASER RADIATION
AVOID DIRECT EYE EXPOSURE
CLASS 3R LASER PRODUCT
IEC 60825-1:2007
21 CFR 1040.10
l: 650 ±10 nm
Pout maximum < 5mW (into free space)
