FTB-200 Compact Platform
ORDERING INFORMATION
Model
FTB-200-v2 = Compact modular platform
Display
S1 = TFT active screen
S2 = Outdoor-enhanced screen
Wi-Fi/Bluetooth hardware option
00 = Without RF components
RF = With RF capability (Wi-Fi and Bluetooth)
Power meter
00 = Without power meter
VPM2X = VFL platform; PM; GeX detector
VPM3 = VFL; PM; InGaAs detector
VPM2X-CWDM = VFL platform; PM; GeX detector;
CWDM wavelengths calibrated
(from 1270 nm to 1610 nm)
VPM3-CWDM = VFL; PM; InGaAs detector;
CWDM wavelengths calibrated
(from 1270 to 1610 nm)
SPFTB200.9AN © 2012 EXFO Inc. All rights reserved. 2008 Printed in Canada 12/03
FTB-200-V2- XX - XX - XX - XX - XX - XX
Example: FTB-200-v2-S1-RF-VPM2X-FOA-16-FP4S-IPT-FPSA
Software option
00 = Without any software option
IPT = Ping and traceroute functionalities
FPSA = ConnectorMax analysis software
FPSAMF = ConnectorMax kit: single-fiber analysis and reporting; multiple-fiber
connector assessment wizard and reporting
Expert-VoIP = RTP-based call testing software application, including packet loss
analysis, jitter measurement and complete voice quality metrics
Expert-IP = IP/Ethernet test suite, with tests including FTP performance, HTTP
availability, VLAN scan, LAN discovery, ping, traceroute, IP/Ethernet
port statistics (license for a single platform)
EXpert-IPTV = IPTV test suite
EXpert-TPP = Triple-play bundle for voice, video and data testing; includes
EXpert IP Test Tools, EXpert IPTV Test Tools, EXpert VoIP Test
Tools and EXpert SIP
EXpert-SIP = SIP call signaling support a
EXpert-SCCP = SCCP call signaling support a
EXpert-H.323 = H.323 call signaling support a
EXpert-H.248 = H.248/Megaco call signaling support a
Probe
00 = Without probe
FP4S = Inspection probe (400x)
FP4D = Inspection probe (200x/400x)
Connector adapter b
FOA- 12 = Biconic
FOA- 14 = NEC D4: PC, SPC, UPC
FOA- 16 = SMA/905, SMA-906
FOA- 22 = FC/PC, FC/SPC, FC/UPC, FC/APC
FOA- 28 = DIN 47256, DIN 47256/APC
FOA- 32 = ST: ST/PC, ST/SPC, ST/UPC
FOA- 54 = SC: SC/PC, SC/SPC, SC/UPC, SC/APC)
FOA- 78 = Radiall EC
FOA- 96B = E-2000 E-2000/APC
FOA- 98 = LC
FOA- 99 = MU
WC2 = FOA-FC-ST-SC-LC
Notes
a. If EXpert VoIP is selected.
b. If power meter is selected.
