5
Multifunction
MC5 is the first of its kind modular ALL-IN-ONE multifunction
calibrator. Within its compact and ergonomic case, MC5 provides
calibration capability for pressure, temperature, electrical and
frequency signals (including pulses). Therefore, MC5 offers calibration
capability for virtually all types of process and other instruments.
Up to 3 internal pressure modules (each having internal overpressure
protection) may be installed in the MC5 case. This together with the
possibility to use external pressure modules, gives MC5 a unique
pressure calibration capability.
A unit fitted with the barometric module allows a single pressure port
to measure gauge, absolute and vacuum pressures.
Only a few modules are required to cover the pressure ranges and
uncertainties demanded by modern industry.
U
NIQUE
M
ODULAR
C
ONSTRUCTION
Modular
The modular construction of MC5 provides flexibility in user specific
requirements. For example, MC5 can be ordered as a pressure or
temperature stand-alone calibrator and then later be expanded into
a datalogging documenting multifunction calibrator. Firmware
updates are installed via the RS port (loaded from a user’s
computer), making it possible to upgrade existing MC5’s with
additional functionality as requirements arise.
True field compatibility
The lightweight MC5 is designed for use in tough
field environments. Its rugged IP65-rated case,
along with the integrated impact protectors, make
MC5 the ideal portable calibrator for use in wet and
dusty environments subject to wide temperature
variations.
The advanced battery technology used by MC5
eliminates the typical concerns associated with
portable calibrators. The powerful, easy to change
NiMH rechargeable battery pack, provides many
hours of field use. The battery pack can be rapidly
charged while the MC5 is in use or when the battery
pack is outside of the unit. Alternately, dry batteries
(6 AA sized) may be used.
Multifunction Calibrator
