4
Input/output characteristics
Front panel connectors
Input
75 Ω BNC female
Cal output 75 Ω BNC, +29 dBmV, 300 MHz
RF out (Option 011) 75 Ω BNC female
Probe power +15 Vdc, –12.6 Vdc, and ground (150 mA max
each)
TV in (Option 107) 75 Ω BNC female
Rear panel connectors
Aux video out
50 Ω BNC, 0-1 V
Monitor out 50 Ω BNC
Selectable format NTSC, 15.75 kHz, 60 Hz
PAL, 15.625 kHz, 50 Hz
High sweep in/out BNC, high TTL = sweep, low TTL = retrace
Sweep output BNC, 5k Ω, 0 to +10 V ramp
Aux IF output 50 Ω BNC, –10 to –60 dBm, 21.4 MHz
External trigger input
(Opt. 107) BNC, TTL levels, positive edge trigger
TV trigger output
(Opt. 107) BNC, TTL levels, negative edge trigger after-
sync pulse
TV monitor output
(Opt. 107) 75 Ω BNC, female, –0.28 to +0.714 V
10 MHz ref output 50 Ω BNC, 10 MHz, 0 dBm
External ref in 50 Ω BNC, 10 MHz, –2 to +10 dBm
RS-232 D connector, 9 pin
Parallel interface D connector, 25 pin
GPIB (Opt. 041) SH1, AH1, T6, L4, SR1, RL1, PP0, DC1, C1, C2,
C3, C28
Earphone 1/8 inch monaural jack
Aux interface 9 pin “D” subminiature
Keyboard 5 pin DIN, Option 003 IBM AT keyboard com-
patible
Gate trigger input (Opt. 107) 50 Ω BNC, pulse ≥30 ns
Gate output (Opt. 107) 50 Ω BNC, TTL levels
Cable TV measurement specifications
Cable TV RF and video measurement
These specifications describe warranted performance of the Agilent CaLan
8591C cable TV analyzer and the CaLan 85721A cable TV measurement
personality from 0° to 50°C after the warmup and calibration described
earlier. Characteristics provide useful, but non-warranted, information
about nominal performance. NTSC-formatted signals only are covered. A
RAM card is needed for the 85721A to store test results. Test data may
also be printed using an HP InkJet or HP LaserJet printer.
Input 75 Ω BNC female connector
Channel selection Analyzer tunes to specified channels based
on selected tune configuration
Tune configuration Standard, off-the-air, HRC, IRC, T and FM
(channel mode)
Channel range 1 to 158 and 201 to 300
1 tp 158 (system mode)
2 to 134 (Opt. 107)
7
Channel frequencies Defined by Code of Federal Regulations, Title
47,Telecommunications, Parts 73.603, 76.605,
76.612
Frequency range 5 to 1002 MHz (channel mode)
54 to 896 MHz (system mode)
50 to 850 MHz (Opt. 107)
7
Amplitude range –15 to +70 dBmV for S/N >30 dB
0 to +60 dBmV for coupler input (Opt. 107)
Visual carrier frequency Visual carrier frequency is counted.
Precision frequency reference (standard)
Resolution
100 Hz
Accuracy ±(1.2 x 10 –7 x carrier frequency + 110 Hz)
At 55.25 MHz (Ch. 2) ±117 Hz
At 325.25 MHz (Ch. 41) ±149 Hz
At 643.25 MHz (Ch. 94) ±187 Hz
Option 704 frequency reference
Resolution
1 kHz
Accuracy ±(7.5 x 10 –6 x carrier frequency + 110 Hz)
At 55.25 MHz (Ch. 2) ±524 Hz
At 325.25 MHz (Ch. 41) ±2.55 Hz
At 643.25 MHz (Ch. 94) ±4.93 Hz
Visual-to-aural carrier
frequency difference
Frequency difference between visual and
aural carriers is counted.
Difference range 4.1 to 4.9 MHz
Resolution 100 Hz
Accuracy ±221 Hz for precision frequency ref (std)
±254 Hz for Option 704 frequency ref
Visual carrier level The peak amplitude of the visual carrier is
measured to an absolute standard traceable
to the National Institute of Standards and
Technology.
Amplitude range –15 to +70 dBmV
Resolution 0.1 dB
Absolute accuracy ±2.0 dB for S/N >30 dB
Relative accuracy ±1.0 dB relative to adjacent channels
in frequency
±1.5 dB relative to all other channels
Visual-to-aural carrier
level difference
The difference between peak amplitudes of
the visual and aural carriers is measured.
Difference range 0 to 25 dB
Resolution 0.1 dB
Accuracy ±0.75 dB for S/N >30 dB
Depth of modulation
(characteristic)
Percent AM is measured from horizontal sync
tip to maximum video level; measurement
requires a white reference VITS and may not
be valid for scrambled channels.
AM range 50 to 93%
Resolution 0.1
Accuracy ±2.0% for C/N >40 dB
