Input attenuator
Range
0 to 70 in 10 dB steps
Accuracy
0 to 60 dB
±0.5 dB at 50 MHz, ref to 10 dB attenuator
70 dB
±1.2 dB at 50 MHz, ref to 10 dB attenuator
Resolution bandwidth
(referred to 3 kHz RBW at ref level)
Switching uncertainty
3 kHz to 3 MHz RBW
±0.4 dB
1 kHz RBW
±0.5 dB
30 Hz to 300 Hz RBW
±0.6 dB (Option 130)
Log to linear switching
±0.25 dB at reference level
Display scale fidelity
Log incremental
accuracy
±0.2 dB/2 dB, 0 to –70 dB from ref level
Log maximum
cumulative accuracy
±0.75 dB, 0 to –60 dB from ref level
±1.0 dB, 0 to –70 dB from ref level
Linear accuracy
±3% of reference level
Internal preamplifier
Frequency range
1 MHz to 1.0 GHz
Gain
≥24 dB
Noise figure
≤10 dB
Option 011 built-in tracking generator
Frequency range
1 MHz to 1.8 GHz
Output power level
Range
+42.8 dBmV to –27.2 dBmV
Resolution
0.1 dB
Absolute accuracy
±1.0 dB (+28.8 dBmV at 300 MHz)
Vernier accuracy
(15° to 35° C)
±0.75 dB (+28.8 dBmV at 300 MHz)
Output flatness
±1.75 dB
Output power sweep
Range
+42.8 dBmV to –32.2 dBmV
Resolution
0.1 dB
Spurious output (+42.8 dBmV output)
Harmonic spurs
<–25 dBc
Non-harmonic spurs
<–30 dBc
Tracking generator
feedthrough
<–57 dBmV
Option 107 TV receiver and time gate
Gate delay
(from gate trigger input to positive edge of
gate output)
Range
1 µs to 65.535 ms
Resolution
1 µs
Accuracy
±1 [µs + (0.01% x gate delay)]
6
Gate length
(from positive edge to negative edge of gate
output)
Range
1 µs to 65.535 ms
Resolution
1 µs
Accuracy
±[0.2 µs + (0.01% x gate length)]
Gate amplitude characteristics
6
Additional log error
±0.3 dB
General specifications
Temperature
Operating
0 °C to +50 °C in carrying case
Storage
–40 °C to +75 °C
EMI compatibility
Conducted and radiated interference CISPR
pub. 11 and FTZ 526/527/79
Audible noise
<37.5 dBA pressure and <5.0 Bels power
(ISO DP7779)
Power requirement
On (line 1)
86-127, or 195-253 Vrms, 47-66 Hz 103-126
Vrms, 400 Hz +10%
Standby (line 0)
Power consumption , 7 W
User memory (nominal)
32 Kbytes non-volative RAM
Data storage (nominal)
50 states and traces, internal memory
8 internal state registers
24 states and traces, memory card
(Agilent 85702A)
Weight (nominal)
18.1 kg (40 lb)
Size (nominal)
213 mm (8.4”) H x 366 mm (14.4”) W x
460 mm (18.1”) D
Warranty
1 year limited warranty for materials and
workmanship
6. With gate enabled and triggered, CW signal, peak detector mode
