10
System Specifications
The DTS-300 system is self-contained and based on the Microsoft
Windows NT platform with disk drive, high-speed 18 GB SCSI,
CD-ROM drive, floppy disk drive, external SCSI interface, and
Ethernet interface (10/100 BaseT).
Portable . . . . . . . . . . . . . . . . . . .TFT display, pointer and keyboard
Desktop . . . . . . . . . . . . . . . . . . . . . .monitor, mouse, and keyboard
BUILT-IN INPUT AND OUTPUT CONNECTIONS
(ASI and SPI interfaces support 188-, 204-, & 208-byte packets)
DVB ASI . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .75 ohm BNC
DVB SPI (LVDS) . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .DB25
SMPTE-310M . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .BNC
SYSTEM CLOCK
Internal Clock . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .27 MHz
Internal Clock accuracy . . . . . . . . . . . . . . . . . . . . . . . . . . . . .5 ppm
Internal Clock stability . . . . . . . . . . . . . . . . . . . . . . . . . .1 ppm/year
Internal Clock resolution . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1Hz
Output Clock (SPI) . . . . . . . . . . . . . . . . . . . . . . .1 kHz to 15 MHz
Input Clock (SPI) . . . . . . . . . . . . . . . . . . . . . . . . . . . .up to 15 MHz
ELECTROMAGNETIC COMPATIBILITY (EMC)
CE . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . EN 50081-1, EN 50082-1
FCC . . . . . . . . . . . . . . . . . . . . . . . . . . . Part 15, Sub Part B, Class A
Safety . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . IEC 1010, EN 61010
MPEG-2 ISO/IEC Protocols . . . . . . . . . . . . .13818-1 /-2 /-3 /-4/-9
ATSC Protocols . . . . . . . . . . . . . . . . . . . . . . . . . . .A/52, A/53, A/65
DVB Protocols . . . . . . .ETS 300 468, ETS 211, ETR 154 / 162 / 290
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .PrEN 50083-9, TS 101191
MAXIMUM DATA RATE
Real-time Analysis/Stream Creation . . . . . . . . . . . . . . . . .214 Mbps
Recording/Playback (to SCSI disk) . . . . . . . . . . . . . . . . . .90 Mbps
Recording/Playback (to memory) . . . . . . . . . . . . . . . . . .214 Mbps
MAXIMUM FILE SIZE
Circular Capture Buffer . . . . . . . . . . . . . . . . . . . . . . . . . . . .128 MB
High-speed Mode . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .128 MB
SCSI Disk . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .disk capacity
Ordering Information
Systems
All systems are self-contained and delivered with cables, software,
demonstration streams, and English user manual.
DTS-300 Analyzer
Analysis System for DVB and ATSC
Portable . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .BN 7551/21
Desktop . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .BN 7551/22
DTS-300 Generator
Play and Record System for DVB and ATSC
Portable . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .BN 7551/11
Desktop . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .BN 7551/12
DTS-300 Multiplexer
Stream Creation System for DVB and ATSC
Portable . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .BN 7551/61
Desktop . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .BN 7551/62
DTS-300 Analyzer/Generator
Allows for simultaneous play and analyze or record capabilities.
Portable . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .BN 7551/41
Desktop . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .BN 7551/42
DTS-300 Multiplexer/Generator
Allows for simultaneous create or play and record capabilities.
Portable . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .BN 7551/71
Desktop . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .BN 7551/72
DTS-300 Analyzer/Multiplexer/Generator
Allows for simultaneous create or play and analyze or record.
capabilities
Portable . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .BN 7551/81
Desktop . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .BN 7551/82
Options
MProbe 110
BN 7551/94.04
Offline analysis and decode of MPEG-2 video/audio and AC-3
elementary streams (ES) including support for packetized
elementary streams (PES).
SyncCheck
BN 7551/94.05
Audio/video synchronization analysis software for ATSC/DVB
streams. Also includes one HD (1290x1080i, 29.97 FPS, and four
audio channels) and one D1-PAL (720x576i, 25FPS, and four
audio channels) lip-sync test video source tapes.
Real-Time Analysis for OpenTV
BN 7551/94.02
Real-time analysis of OpenTV applications and carousels over
MPEG-2/DVB transport streams. Only available for configurations
BN 7551/2x, /4x and /8x.
Dual Analysis
BN 7551/92.21 (portable); BN 7551/92.22 (desktop)
Simultaneous dual analysis option. Provides application software
and additional SMPTE-310M, ASI, and SPI input hardware. Only
available for analysis systems BN 7551/2x, /4x and /8x. Not avail-
able in conjunction with Dual Play, DHEI, or QPSK options.
Dual Play
BN 7551/92.11 (portable); BN 7551/92.12 (desktop)
Simultaneous dual play option. Provides application software,
additional 18 GB SCSI hard drive, and additional SMPTE-310M,
ASI, and SPI output hardware. Only available for desktop generator
systems BN 7551/12, /42, /72 and /82. Not available in conjunction
with Dual Analysis, DHEI, or QPSK options.
Continued on back page.
