Electromagnetic Compatibility:
IEC 61326-1:1997+A1:
CISPR 11:1990/EN 55011:
IEC 61000-4-2:1995+A1:
IEC 61000-4-3:
IEC 61000-4-4:
IEC 61000-4-5:
IEC 61000-4-6:
IEC 61000-4-11:
Canada:
Australia/New Zealand:
1998/EN 61326-1:1997+A1:1998
1991 Group 1 Class A
1998/EN 61000-4-2:1995(ESD 4kV CD,8kV AD)
1995/EN 61000-4-3:1995(3V/m,80% AM)
1995/EN 61000-4-4:1995(EFT 0.5kV line-line,1kV line-earth)
1995/EN 61000-4-5:1995(Surge 0.5kV line-line,1kV line-earth)
1996/EN 61000-4-6:1996(3V,0.15~80 MHz,80% AM,power line)
1994/EN 61000-4-11:1994(Dips 1 cycle,100%)
ICES-001:1998
AS/NZS 2064.1
IEC 61010-1:
Safety:
2001/EN61010-1:2001,CSA C22.2 No.61010-1:2004,UL61010-1:2004
Operating:
Non-operating:
Temperature:
-10 ℃ to +50℃, humidity 85% or less
-40 ℃ to +70℃ (Recommend the battery be stored separately below 0 ℃
and above+40 ℃ for any prolonged non-operating storage period.)
Environmental: According to Agilent Environmental Test Manual class OE, except Temperature
Power Supply:
External DC Input:
+11 to +25 volt dc, 40W min.
Internal battery: Rechargeable Lithium-ion battery, 4 hours operating time
Size(w x h x d):
Weight:
Dimensions:
317mm x 207 mm x 69 mm (12.5 in x 8.1 in x 2.7 in)
Net weight: 2.6 kg (5.73 lbs)
Weight with battery: 2.9 kg (6.39 lbs)
Input and output ports:
RF Test Port:
Maximum Input without Damage:
USB master:
USB slave:
Type N, female, 50 W
+25 dBm, ±50 VDC
1 x A plug
1 x B plug
v1.1 protocol
v1.1 protocol
Soft carrying case
N9330A handheld cable and antenna tester
Spare rechargeable battery
Phase-stable extension cable
Automotive 12V DC adaptor
Electronic calibrator
‘ T-combo'
open/short/50 ohm load
Hard transit case
11
