N9330A Handheld Cable and Antenna Tester Specifications
T est functions
Frequency Range
Frequency Resolution:
Output Power:
Measurement Speed:
Number of Data Points:
Return Loss
:
SWR:
Cable Loss:
Measurement Accuracy:
Distance-to-Fault:
Range:
Resolution:
Markers:
User storage:
General
Display: 7.2" 640x480 transflective color LCD with adjustable backlight
Instrument setup storage:
Trace data storage:
Screen pictures storage:
up to 15
up to 200 traces
10 screens
Support USB memory stick for instrument setup and trace data storage
Resolution (meter)=(1.5 x 10 )x (Vp)/(f2-f1)Hz
Where Vp is the cable's relative propagation velocity.
where f2 is the stop frequency and f1 is start frequency.
(Number of data points - 1)x Resolution
Number of data points=521, 261, or 131
Vertical Range: Return Loss: 0.00 to 60.00 dB
SWR 1.00 to 65.00
>42 dB corrected directivity after mechanical calibration
Range:
Resolution:
0.00 to 30.00 dB
0.01 dB
Range:
Accuracy:
Resolution:
1.00 to 65.00
same as RL
0.01
Range:
Accuracy:
D:
RL:
Resolution:
0.00 to 60.00dB
directivity of calibrator.
return loss value of DUT.
0.01 dB
(maximun): 521 (selectable 521, 261, 131)
2 second / screen (full span, 521 data point, CW sweep mode)
0~-20 dBm
100 kHz
25 MHz to 4.0 GHz
Return loss
SWR
Cable loss
Distance-to-fault(DTF)
6
Internal user flash memory:
10
8
A=20×log10(1.1+10 +0.016×10 +10 ) (-(D-RL)/20) (-RL/20) (-3+RL/20)
