Footnotes:
1. The RFP bypass switch connects input
#2 directly to the RF output.
2. Refer to spectrum analyzer test and
adjustment manual for the correct
frequency reference adjustment.
3. Refer to spectrum analyzer data sheet
for filter BW accuracy and filter shape.
4. 17 dB higher with 8566B for frequency
< 50 kHz.
5. Sensitivity is approximately equal to
system peak noise level.
6. Peak noise is nominally 8 dB higher
than average noise.
7. Measurement sensitivity is normalized
to 1 MHz resolution BW.
8. Specifications apply after system
calibration with the comb generator
in the 85685A. Refer to 85685A operat-
ing manual for correct amplitude mea-
surement technique.
9. The system meets CISPR publication
16 recommendations for resolution
BW, detector time constant, and
detector pulse response.
10. System calibration can be verified with
an external CISPR standard pulse cali-
bration generator.
11. Typical LISN transients.
12. SWR is measured at the tuned
frequency of the spectrum analyzer.
13. Refer to the EMI measurement
solutions guide (5954-2702) for more
information.
