R3132/3162-9E Jan. '02
Frequency
Frequency range:
Frequency reading accuracy:
(Start, stop, center frequency,
marker frequency)
Counter
Resolution:
Accuracy:
Frequency reference accuracy
Stability:
Frequency span
Range:
Accuracy:
Residual FM:
Signal purity:
* RBW 300 Hz (Option 27)
Resolution bandwidth (3 dB)
Range:
Accuracy:
6 dB bandwidth:
Video bandwidth:
Amplitude range
Measuring range:
Maximum input level
(Input ATT 10 dB)
Preamplifier OFF:
Preamplifier ON:
Indication range:
Log:
Linear:
Reference level range
Preamplifier OFF:
Log:
Linear:
Preamplifier ON:
Log:
Linear:
Input AT T range:
Dynamic range
Average nose level:
Preamplifier OFF:
Preamplifier ON:
1 dB gain compression:
Preamplifier OFF:
Preamplifier ON:
Spurious response:
2nd-order harmonic
distortion:
2 signal 3rd-order
intermodulation distortion:
Residual response:
Preamplifier OFF:
Preamplifier ON:
9 kHz to 3 GHz
(Reading of frequency x Frequency reference
accuracy + Span x 1% + RBW x 15% + 60 Hz)
1 Hz to 1 kHz
(Marker frequency x Frequency reference accuracy
+ 1LSD)
(S/N 25 dB, span 200 MHz)
2 x 10 -6 /year, 1 x 10 -7 /year (Option 20)
1 x 10 -5 (0 to 50 °C ), 2 x 10 -8 /day (Option 20)
1 kHz to 3 GHz, 0 Hz (zero span)
1%
60 Hzp-p/0.1s, 20 Hzp-p/0.1s (Option 20)
offset f 2.6 GHz f > 2.6 GHz
20 kHz -105 dBc/Hz -103 dBc/Hz
10 kHz -100 dBc/Hz* -98 dBc/Hz*
1 kHz to 3 MHz, 1-3-10 sequence
30 Hz, 100 Hz, 300 Hz (Option 27)
< 20%, 1 kHz to 1 MHz
< 25%, 3 MHz
< 20% (added with Option 27)
1 MHz, 120 kHz, 9 kHz
200 Hz (Option 27)
10 Hz to 3MHz, 1-3-10 sequence
+134 dB V to average noise level
+134 dB V, 50 VDC max.
+120 dB V, 50 VDC max.
10 x 10 div
10, 5, 2, 1 dB/div
10% of the reference level/div.
(Input ATT: 0 to 50 dB)
+44.8 dB V to +148.8 dB V (0.1 dB step)
172.8 V to 27.39 V
(Input ATT: 0 to 30 dB)
+26.8 dB V to +118.8 dB V (0.1 dB step)
21.75 V to 866 mV
0 to 50 dB (5 dB step)
RBW 1 kHz, VBW 10 Hz, input ATT 0 dB,
f 10 MHz
-6 dB V + 2f (GHz) dB
-21 dB V + 3f (GHz) dB
f 200 MHz
> +107 dB V (mixer input level)
> +82 dB V (RF input level)
Preamplifier OFF, Mixer input +77 dB V
-70 dBc (100 MHz f <800MHz)
-80 dBc (f 800MHz)
-80 dBc (f 200 MHz, Offset >50 kHz)
When input ATT 0 dB, 75 terminated,
and 1 MHz to 3 GHz
+7 dB V
+2 dB V
After auto calibration at ATT = 10 dB
0.5 dB (100 kHz to 2.2 GHz)
2 dB (9 kHz to 2.2 GHz)
1 dB (100 kHz to 2.2 GHz)
2 dB (9 kHz to 2.2 GHz)
-20 dBm 0.3 dB
After auto calibration
< 0.5 dB
After auto calibration
1.5 dB/80 dB
1dB/10 dB
0.2 dB/1 dB
5% of reference level
0.3 dB (for 0 to 50 dB, with reference to
30 MHz/10 dB)
After auto calibration
< 0.5 dB
1.5 dB (REF = +57 to +107 dB V, AT T = 10 dB,
2 dB/div, RBW = 300 kHz, 100 kHz < f 2.2GHz
after auto calibration)
20 ms to 1000 s, 50 s to 1s (Option 29, zero span)
< 2%
FREE RUN, LINE, VIDEO, EXT, TV,
REPEAT, SINGLE
N type female
75 (nominal)
<1.5:1 (100 kHz to 2.2 GHz)
Input ATT = 10 to 50 dB
<2:1 (9 kHz to 2.2 GHz)
Input ATT = 5 to 50 dB
<2.5:1 (9 kHz to 2.2 GHz)
12 V, 4-pin connector
BNC female, 75 (nominal)
30 MHz, -20 dBm
BNC female, 500 (nominal)
-10 to +10 dBm
BNC female
Small monophonic jack
IEEE-488 BUS connector
D-sub 9-pin
D-sub 25-pin, ESC/P, ESC/P-R, PCL
VGA (15-pin, female)
3.5-inch, MS-DOS format
0 to +50 °C, Relative humidity 85% or less
(no dew condensation)
-20 to +60 °C, relative humidity 85% or less
100/200 VAC auto-switchable
100 VAC: 100 to 120 VAC, 50 to 60 Hz
200 VAC: 200 to 240 VAC, 50 to 60 Hz
200 VA or less
Approx. 424 (W) x 177 (H) x 300 (D) mm
(excluding feet and connectors)
14 kg or less
(excluding options, cover, and accessories)
R3132N Specifications Amplitude accuracy
Frequency response:
Preamplifier OFF:
Preamplifier ON:
Calibration signal level
accuracy:
IF gain error:
Scale indication accuracy:
Log:
Linear:
Input ATT switching error:
Resolution bandwidth
switching level error:
Total level accuracy:
Sweep
Sweep time:
Accuracy:
Trigger mode:
Sweep mode:
I/O
RF input
Connector:
Impedance:
VSWR
Preamplifier OFF:
Preamplifier ON:
Probe power:
Calibration output signal:
10 MHz reference input:
External trigger input:
Sound output
(demodulated audio):
GPIB interface:
RS232 interface:
Printer interface:
Video output:
Floppy disk:
General specifications
Operating temperature:
Storage temperature:
Power supply:
Power consumption:
Dimensions:
Mass:
