3
Specifications
Specifications describe the instrument's warranted performance. Non-warranted values are described
as typical. All specifications apply after a 30 minute warm-up phase with 50
W source/load resistance
and separate channels. All specifications are valid from 0°C to 55°C ambient temperature.
Timing Characteristics
Measured at 50% amplitude at fastest transitions in continuous mode and 50 W source impedance.
Mainframe
Output module
Agilent 8133A
Pulse Channel 1
Delay Pulse Channel 1
Option 001
Pulse Channel 2
Option 003
Pulse/Data Channel 2
Option 002
Frequency Range 33.0 MHz to 3.0000 GHz
Period Range 333 ps to 30.303 ns
Timing resolution 3.5 digits, 1 ps best case
RMS Jitter (period, delay, width)
less than 5 ps (1 ps typical)
10 ps ( f<2 GHz: 5ps)
Accuracy ±± 0.5% (±± 0.1% typical)
Width range [1] 150 ps to (period – 150 ps) maximum 10.000 ns
Resolution 1ps
Accuracy ±± 100 ps (±± 30 ps typical)
Duty Cycle [2] 0% to 100%
Resolution 0.1%, best case 1
Add. Variable delay
Pulse mode: no
Square mode: 0.000 ns
10.000 ns
Pulse mode: -5.000
to + 5.000ns
Square mode: -5.000
ns to 15.000 ns
[3] Pulse mode: no
Square mode: 0.000 ns to 10.000 ns
Channel 1 to Channel 2 Delay [4] Pulse mode: -5.000 ns to + 5.000 ns
Square mode: -5.000 ns to 15.000 ns
Resolution 1 ps
Accuracy [5] ±± 150 ps (±± 30 ps typical) [6] ±± 50 ps
Phase [7] 0°° to 3600°° -3600°° to 3600°° -3600°° to 3600°° -3600°° to 3600°°
Resolution 0.1°°, best case 1 ps
Skew [8] ±± 5 ns
Notes:
[1] The width can only be varied in Pulse mode. In square mode the duty cycle is fixed at 50%
[2] Width and duty cycle are mutually exclusive. Duty Cycle settings and limits are subject to the same specifications and settings as
Width.
[3] Delay variation Channel 2 to Channel 1
[4] The interchannel delay between Channel 1 and Channel 2 is the programmed delay of Channel
[5] Any parameter variation
[6] Only delay variation
[7] Delay and Phase are mutually exclusive. Phase settings and limits are subject to the same specifications and settings as
[8] Delay or Phase, plus Skew must be within the Delay Range
Repeatability: is typ. four times better
than accuracy.
Internal Clock Generation
The internal clock can be set in
frequency or period mode
External Clock
The external input signal determines
the timebase of the instrument. The
external period or frequency is
measured and displayed, allowing the
correct setting of Duty Cycle and
Phase also in External Clock mode.
External Frequency Counter Period
Range:
333 ps to 30.303 ns (300 ps to
500 ns typical)
Resolution: 1 ps
Accuracy: ± 0. 1 %
