6
Service options
Warranty and Calibration 1
R-50C-011-3: Agilent Calibration Upfront
Plan 3-year coverage
R-50C-011-5: Agilent Calibration Upfront
Plan 5-year coverage
R-51B-001-3C: 1 year Return-to-Agilent
warranty extended to 3 years
R-51B-001-5C: 1 year Return-to-Agilent
warranty extended to 5 years
The E9320 Series power sensors have a
12-month return-to-Agilent warranty and
service plan. For more information,
contact your local sales and service office.
E-series E9320 power sensor
specifications
The E9320 peak and average power sensors are designed
for use with the EPM-P series power meters. The E9320
sensors have two measurement modes:
Normal mode (default mode for E9320 sensors) for
peak, average and time-related measurements
Average only mode is designed primarily for average
power measurements on low-level signals. This mode is
the only mode used with 8480 and N8480 series sensors,
E-series CW sensors and E-series E9300 sensors.
The following specifications are valid after zero and cali-
bration of the power meter.
Note: E9320 power sensors MUST be used with an
E9288A, B or C cable.
Table 3. Sensor specifications
Sensor
model
E9321A
E9325A
E9322A
E9326A
E9323A
E9327A
Video
bandwidth
300 kHz
1.5 MHz
5 MHz
Frequency range
50 MHz to 6 GHz
50 MHz to 18 GHz
50 MHz to 6 GHz
50 MHz to 18 GHz
50 MHz to 6 GHz
50 MHz to 18 GHz
Power range
Average only mode Normal mode 2
-65 dBm to +20 dBm -50 dBm to +20 dBm
-60 dBm to +20 dBm -45 dBm to +20 dBm
-60 dBm to +20 dBm -40 dBm to +20 dBm
Maximum power
+23 dBm average;
+30 dBm peak
(< 10
msec duration)
Connector
type
Type N (m)
1. Options not available in all countries.
2. For average power measurements, free run acquisition.
