background image

16

Specifications (continued)

Calibration factor and reflection
coefficient

Calibration factor (CF) and reflection
coefficient (Rho) data is unique to
each sensor. The CF corrects for the
frequency response of the sensor.
The reflection coefficient (Rho or ρ)
relates to the SWR based on the fol-
lowing formula:

SWR =

1 + ρ

1 – ρ

Maximum uncertainties of the CF
data are listed in the following table.
There is only one set of CF data used
for both high and low power paths of
each sensor.

The uncertainty analysis for the cali-
bration data was done in accordance
with the ISO Guide. The uncertainty
data reported on the calibration cer-
tificate is the expanded uncertainty
with a 95% confidence level and a
coverage factor of 2.

Frequency

Uncertainty (%) (25 °C ± 10 °C)

U2000A sensor

10 to 30 MHz
30 MHz to 2 GHz
2 to 14 GHz
14 to 16 GHz
16 to 18 GHz

1.8
1.6
2.0
2.2
2.2

U2001A sensor

10 to 30 MHz
30 MHz to 2 GHz
2 to 6 GHz

1.8
1.6
2.0

U2002A sensor

50 MHz to 2 GHz
2 to 14 GHz
14 to 16 GHz
16 to 18 GHz
18 to 24 GHz

2.0
2.5
2.7
2.7
3.0

U2004A sensor

9 kHz to 2 GHz
2 to 6 GHz

1.8
1.8

U2000B sensor

10 MHz to 2 GHz
2 to 12.4 GHz
12.4 to 18 GHz

1.8
2.0
2.2

U2001B sensor

10 MHz to 2 GHz
2 to 6 GHz

1.8
2.0

U2000H sensor

10 MHz to 8 GHz
8 to 12.4 GHz
12.4 to 18 GHz

2.0
2.0
2.2

U2001H sensor

10 MHz to 6 GHz

2.0

U2002H sensor

50 MHz to 8 GHz
8 to 12.4 GHz
12.4 to 18 GHz
18 to 24 GHz

2.5
2.5
2.7
3.0
