8
Digital multimeter specifications
• Accuracy is given as ± (% of reading + counts of least significant digit) at 23 °C ± 5 °C, with relative humidity < 80 RH.
• AC V specifications are AC coupled, true RMS and are valid from 5% to 100% of range.
Maximum reading 10,000 counts with automatic polarity indication
Voltage CAT II 1000 V or CAT III 600 V
Function Range Resolution Accuracy Input impedance
(nominal)
Test current
DCV 1000.0 mV 0.1 mV 0.09% + 5 11.11 MΩ
10.000 V 0.001 V
0.09% + 2
10.10 MΩ
100.00 V 0.01 V
10.01 MΩ
1000.0 V 2 0.1 V 0.15% + 5
ACV
1000.0 mV 0.1 mV
1% + 5 (40 to 500 Hz)
10.00 MΩ
2% + 5 (500 Hz to 1 kHz)
10.000 V
100.00 V 0.001 V
0.01V
1% + 5 (40 to 500 Hz)
1% + 5 (500 Hz to 1 kHz)
2% + 5 (1 to 2 kHz)
1000.0 V 2 0.1 V
1% + 5 (40 to 500 Hz)
1% + 5 (500 Hz to 1 kHz)
ACV + DCV
1000.0 mV 0.1 mV
1.1% + 10 (40 to 500 Hz)
10.00 MΩ
2.1% + 10 (500 Hz to 1 kHz)
10.000 V
100.00 V 0.001 V
0.01 V
1.1% + 7 (40 to 500 Hz)
1.1% + 7 (500 Hz to 1 kHz)
2% + 5 (1 to 2 kHz)
1000.00 V 2 0.1 V
1.2% + 10 (40 to 500 Hz)
1.2% + 10 (500 Hz to 1 kHz)
Diode 3 1 V 0.001 V 0.3% + 2 ~0.5 mA
Beeper < ~50 mV, Single tone for normal forward-biased diode or semiconductor junction of
0.3 V ≤ reading ≤ 0.8 V 8
Instant continuity 3 Continuous beep when resistance < 10 Ω 8
Resistance 1000.00 Ω 4 0.1 Ω
0.3% + 3
0.5 mA
10.000 kΩ 4 0.001 kΩ 50 µA
100.00 kΩ 0.01 kΩ 4.91 µA
1000.0 kΩ 0.1 kΩ 447 nA
10.000 MΩ 0.001 MΩ 0.8% + 3 112 nA
100.00 MΩ 5 0.01 MΩ 1.5% + 3 112 nA
Capacitance 1000.0 nF 0.1 nF
1.2% + 4 6 10.000 μF 0.001 μF
100.00 μF 0.01 μF
1000.0 μF 0.1 μF
2% + 4 6
10.000 mF 0.001 mF
