Specifications
U1610A U1620A
Specification
Vertical system
Bandwidth (-3 dB) 1 100 MHz 200 MHz
DC vertical gain accuracy 1 ± 4% of full scale
Full scale is equivalent to 8 div
Dual cursor accuracy 1 ± {DC vertical gain accuracy + 0.4% full scale (~1 least significant bit (LSB)}
± {4% full scale ± 0.4% full scale (~1 LSB)}
Characteristic
Acquisition
Maximum Sampling Rate
Single Chanel Operation 1 GSa/s interleave 2 GSa/s interleave
Dual Channel Operation 500 MS/s each channel 1 GS/s each channel
Maximum Recording Length
Single Chanel Operation 120 Kpts interleave 2 Mpts interleave
Dual Channel Operation 60 Kpts each channel 1 Mpts each channel
Vertical resolution 8 bits
Peak detection > 10 ns > 5 ns
Average Selectable from 2 to 8192 in powers-of-2 increments
Filter 10 kHz and 20 MHz bandwidth limiters
Interpolation (Sin x)/x
Vertical system
Analog channels Channel 1 and Channel 2 simultaneous acquisition
Calculated rise time 3.50 ns typical 1.75 ns typical
Vertical scale 2 mV/div to 50 V/div
Maximum input CAT III 600 Vrms (with 10:1 probe)
CAT III 300 Vrms (direct / 1:1 probe)
Offset (position) range ± 4 div
Dynamic range ± 8 div
Input impedance 1 MΩ ± 1% ≈ 22 pF ± 3 Pf
Coupling DC, AC
Bandwidth limit 10 kHz and 20 MHz (selectable)
Channel-to-channel isolation
(with channels at the same V/div) CAT III 600 Vrms
Probes U1560-60002 1:1 passive probe
U1561-60002 10:1 passive probe
U1562-60002 100:1 passive probe
Probe attenuation factors 1x, 10x, 100x
Probe compensation output 5 V
pp
, 1 kHz
Noise peak-to-peak (typical) 3% of full scale or 5 mV
pp
, whichever greater
DC vertical offset (position) accuracy ± 0.1 div ± 2 mV ±1.6% offset value
Single cursor accuracy ± {DC vertical gain accuracy + DC vertical offset accuracy + 0.2% full scale (~½ least
significant bit (LSB)}
± {4% full scale ± 0.1 div ± 2 mV ± 1.6% offset value + 0.2% full scale (~½ LSB)}
!
!
