8
Delay characteristics
Aperture frequency . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . % to 100% of span, where N is number of points
Accuracy (at 23 ±5°C, SPC)
In general, the following formula can be used to determine the accuracy, in seconds, of a specific group
delay measurement:
Phase accuracy [deg]
(sec)
360 [deg] x aperture [Hz]
Depending on the aperture, input level, and device length, the phase accuracy used in either incremental
phase accuracy or worst case phase accuracy.
General characteristics
Operating conditions
When disk drive is in operation
Temperature . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 10 to 40°C
Humidity (at wet bulb
≤
29°C, without condensation) . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 15%
≤
RH
≤
80%
When disk drive is not in operation
Temperature . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5 to 40°C
Humidity (at wet bulb
≤
29°C, without condensation) . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 15%
≤
RH
≤
80%
Altitude. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 0 to 2,000 meters
Warm-up time . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 30 minutes
Non-operating conditions
Temperature . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . – 20 to 60 °C
Humidity (at wet bulb
≤
40°C, without condensation) . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 15%
≤
RH
≤
90%
Altitude .. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 0 to 4,572 meters
Safety . . . . . . . . . . . . . . Certified by CSA-C22.2 No.1010.1-92, Based on IEC 1010-1(1990) including Amendment 1(1992)
EMC
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . Complies with CISPR 11(1990)/EN 55011(1991): Group 1, Class A
Complies with IEC 801-2 (1991)/EN 55082-1(1992): 4 kV CD, 8 kV AD
Complies with IEC 801-3 (1984)/EN 55082-1(1992): 3 V/m
Complies with IEC 801-4 (1988)/EN 55082-1(1992):1 kV power lines, 0.5 kV signal lines
Note: When tested at 3 V/m according to IEC 801-3/1984, the averaging noise level will be within specifications over the full immunity test frequency range of 26 to 1000 MHz
except when the analyzer frequency is identical to the transmitted interference signal test frequency.
Power requirement. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 90 to 132 V or 198 to 264 V, 47 to 63 Hz, 400 VA max
Weight (depending on option) . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 12 kg (SPC)
Cabinet dimensions . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 425(W) x 177(H) x 425(D) mm (SPC)
200
N–1
