DATA SHEET > UCS 500N5E > 20130322

TECHNICAL DETAILS

EFT/BURST GENERATOR

UCS 500N5E

As per EN/IEC 61000-4-4 and
EN 61000-6-1, -6-2

Test voltage

200V - 5,500V ± 10%;
100V - 2,750V ± 10% into 50ohm

Pulse shape

5/50ns into 50ohm and 1,000ohm

Rise time tr

5ns ± 30% into 50ohm;
5ns ± 30% into 1,000ohm

Pulse width td

50ns ± 30% into 50ohm;
50ns -15/+100ns into 1,000ohm

Source impedance

50ohm

Polarity

Positive/negative

TRIGGER CIRCUIT

Trigger of bursts

Automatic, manual, external

Synchronization

0° - 360°, resolution 1° (16 - 500Hz)

Burst duration

td = 0.10ms - 999ms

Repetition rate

tr = 10ms - 9,999ms

Spike frequency

f = 0.1kHz - 1,000kHz

Test duration

T = 0:01min - 99:59min
T > 99:59min --> endless

OUTPUTS

Direct

Via 50ohm coaxial connector

Coupling mode

L, N, PE; all combinations

DUT supply

AC: 300V/16A; 50/60Hz
DC: 300V/16A

CRO trigger

5V trigger signal for oscilloscope

EFT/BURST GENERATOR

TEST ROUTINES

Quick Start

On-line adjustable parameters,
easy-to-use

Standard Test
routines

As per IEC 61000-4-4, Levels 1 - 4
As per EN 61000-6-1, -6-2
Manual Standard Test routine

User Test routines

Synchronous burst release
Random burst release
Change voltage after T
Frequency sweep within one burst
Frequency sweep with constant
number of pulses
Frequency sweep with constant
burst duration
Change polarity after T
