DATA SHEET > PFS 200N-series > 20100408
TECHNICAL DETAILS
PFS 200N MODELS
PFS 200N30 Power Fail Simulator 60V/30A
PFS 200N50 Power Fail Simulator 60V/50A
PFS 200N100 Power Fail Simulator 60V/100A
PFS 200N150 Power Fail Simulator 60V/150A
PFS 200N200 Power Fail Simulator 60V/200A
TECNICAL DATA PFS 200N30
DUT voltage Max. 60V for channels PF1/PF2
DUT current Max. 30A for channels PF1/PF2
Switching time 1us (rise/fall time)
Peak current 70A for 500ms
Safety Short circuit protection
TECNICAL DATA PFS 200N50
DUT voltage Max. 60V for channels PF1/PF2
DUT current Max. 50A for channels PF1/PF2
Switching time 1us (rise/fall time)
Peak current 100A for 500ms
Safety Short circuit protection
TECNICAL DATA PFS 200N100
DUT voltage Max. 60V for channels PF1/PF2
DUT current Max. 100A for channels PF1/PF2
Switching time 1us (rise/fall time)
Peak current 150A for 500ms
Safety Short circuit protection
TECNICAL DATA PFS 200N150
DUT voltage Max. 60V for channels PF1/PF2
DUT current Max. 150A for channels PF1/PF2
Switching time 1us (rise/fall time)
Peak current 200A for 500ms
Safety Short circuit protection
TECNICAL DATA PFS 200N200
DUT voltage Max. 60V for channels PF1/PF2
DUT current Max. 200A for channels PF1/PF2
Switching time 1us (rise/fall time)
Peak current Greater than 200A
Safety Short circuit protection
TRIGGER
Automatic Automatic release of the events
Repetition rate 100ms to 999s
Dip/drop duration
td 1us to 10s
Manual Manual release of a single event
CRO Trigger Trigger for oscilloscope, +15V edge
External External release of a single event
TEST ROUTINES
Quick Start Immediate start; easy-to-use and
fast
Chrysler Voltage Drop Out
Voltage Dig
Mechanical Switching
Ford Drop Out High
Drop Out Low
Drop Out Single
Power Dip
RSA/Renault Micro interruptions
Service Service, setup, self test
GENERAL DATA
Dimensions,
weight 19"/3HU, approx. 15kg;
19"/6HU, approx. 18kg for
PFS 200N150 and PFS200N200
Supply voltage 115V/230V +10/-15%
Fuses 2 x T 1AT
INTERFACE
Interface USB
Parallel interface IEEE 488, adresses 1 to 30
Analog interface OVdc to 10Vdc to control an
external dc source (e.g. RDS 200N)
OPTIONS
iso.control Software to control the test,
including standard library, test
report facility and data conservation
generator
www.emtest.com © EM TEST > PAGE 3/4
