General
Power 115/230 VAC
50/60 Hz, single phase 16A
Breaker 2 pole, 20A
Cooling active cooling, air ventilation
Environmental conditions 10°C - 40°C
Dimensions, 50.3 x 42.2 x 52.1 cm
19.8 x 16.6 x 21.7 in
Weight 20.5 kg (45.0 lb)
Control Interface
GPIB Adaptor USB to GPIB adaptor included
(NI-GPIB-USB-HS)
Connections
RF Out Type N Male (front)
Monitor Port In Type N Male (front)
Signal Generator Out Type N Male (rear)
Amplifier In Type N Male (rear)
Pulse In BNC Male (rear)
Communication GPIB (IEEE 488) (rear)
Directional Coupler Fwd Out
(with Option 1) Type SMA (rear)
Directional Coupler Fwd In
(with Option 1) Type SMA (rear)
Directional Coupler Rev Out
(with Option 2) Type SMA (rear)
Directional Coupler Rev In
(with Option 2) Type SMA (rear)
Monitor Port Out Type SMA (rear)
Monitor Port In Type SMA (rear)
Power Meter Calibration Port Out Type SMA (rear)
Control Software
emcw ar e® Software Suite
PC Requirements
Computer 2 GHz Single Core Processor
Operating system Windows, XP, Windows Vista,
Windows 7
RAM 1 GB Minimum
Screen Resolution 1024 x 768
Ports 2 available USB 2.0 ports
Options
1 Directional coupler and additional power head to level
on and monitor forward power
2 Additional power head to add the ability to monitor
reverse power
3 Data acquisition card
4 Laptop PC with software preinstalled
5 100 kHz to 6 GHz Signal Generator SG6000
(Replaces standard Signal Generator SG1200)
6 ISO 17025-accredited calibration for system
7 Amplifier removed; requires use of external amplifier.
MODEL CONFIGURATIONS
MODEL DESCRIPTION
CI00250AM1 Includes Option 4
CI00250AM2 Includes Option 1
CI00250AM3 Includes Options 1 and 4
CI00250AM4 Includes Options 1 and 3
CI00250AM5 Includes Option 5
CI00250AM6 Includes Options 3 and 5
CI00250AM7 Includes Option 6
CI00250AM8 Includes Options 3 and 6
CI00250AM9 Includes Options 3 and 4
CI00250AM10 Includes Options 1, 3 and 4
CI00250AM11 Includes Option 7
CI00250AM12 Includes Options 4 and 6
Accessory Kits
Application Model Description
IEC 61000-4-6
BCI Clamp
50 Ω System
TK1000 Conducted immunity test kit containing all the attenuators, injection
probes, calibration fixtures, calibration resistors, and termination
resistors necessary for IEC testing.
IEC 61000-4-6
BCI Clamp
150 Ω System
TK1001 Conducted immunity test kit containing all the attenuators, injection
probes, calibration fixtures, calibration resistors, and termination
resistors necessary for IEC testing.
IEC 61000-4-6
EM Clamp
50 Ω System
TK1002 Conducted immunity test kit containing all the attenuators, injection
probes, calibration fixtures, calibration resistors, and termination
resistors necessary for IEC testing.
