4
Connector type Frequency range (GHz)
Measured SWR
1.0 to 1.35
Measured SWR
1.35 to 1.86
Male Type -N
dc to 12.4
12.4 to 18.0
±0.025
±0.031
±0.041
±0.050
Female Type -N
dc to 8.0
8.0 to 12.4
12.4 to 18.0
±0.025
±0.031
±0.042
±0.046
±0.063
±0.071
Male SMA
dc to 8.0
8.0 to 12.4
12.4 to 18.0
±0.031
±0.045
±0.077
±0.054
±0.084
±0.137
Female SMA
dc to 8.0
8.0 to 12.4
12.4 to 18.0
±0.054
±0.077
±0.122
±0.088
±0.132
±0.206
Male APC-3.5
dc to 8.0
8.0 to 12.4
12.4 to 18.0
±0.025
±0.031
±0.045
±0.041
±0.050
±0.067
Female APC-3.5
dc to 10
10 to 18
18 to 26.5
±0.020
±0.025
±0.035
±0.031
±0.037
±0.050
Table 1. SWR data uncertainties
Table 2. Coaxial attenuator calibration frequencies* (MHz)
100 4500 9000 13000 16750
500 5000 9500 13500 17000
1000 5500 10000 14000 17250
1500 6000 10500 14500 17500
2000 6500 11000 15000 17750
2500 7000 11500 15500 18000
3000 7500 12000 16000
3500 8000 12400 16250
4000 8500 12500 16500
(each 250 MHz
to 26.5 GHz
*dc to 12.4 GHz models include 26 frequencies, dc to 18 GHz
models include 42 frequencies, dc to 26.5 GHz models include
67 frequencies (2 to 26.5 GHz).
Table 3. Attenuation data uncertainties
Attenuation
(dB)
0.1 to 2.0 GHz 2 to 6 GHz 6 to 12.4 GHz 12.4 to 18.0 GHz 18.0 to 26.5 GHz
3 ±0.07 ±0.06 ±0.07 ±0.11 ±.15
6 ±0.07 ±0.07 ±0.07 ±0.11 ±.15
10 ±0.08 ±0.07 ±0.08 ±0.12 ±.15
20 ±0.09 ±0.08 ±0.09 ±0.13 ±.15
30 ±0.12 ±0.11 ±0.12 ±0.15 ±0.18
40 ±0.15 ±0.14 ±0.15 ±0.21 ±0.25
50 ±0.23 ±0.23 ±0.23 ±0.34 n/a
60 ±0.50* ±0.48* ±0.90* ±0.90* n/a
8491, 8492 and 8493 Attenuation data uncertainty
(dB)
*The uncertainties noted represent 99.7% probability values.
