ac amplitude accuracy at 50/60 hz
Voltage and current Sources
From 20° to 30° C: <0.02% typical, 0.09%
guaranteed
Typically 0.02% of reading
convertible Source in current Mode
From 20° to 30°C: <0.5% guaranteed
Distortion at 50/60 hz
Voltage
and current Sources
Total Harmonic Distortion (THD) < 0.02%
typical < 0.1% guaranteed
phase angle
Range: 0 to +359.9° (Lead) / 0
to –359.9° (Lag)
accuracy: ±0.25° at 50/60 Hz
Resolution: ±0.1° at 50/60 Hz
Frequency
Bandwidth: dc to 3 kHz at full pow-
er for transient playback
Range: dc; ac from 0.1 Hz to 2
kHz at full power continu-
ous load
Resolution: 0.001 Hz
accuracy: 0.5 ppm Typical
1.5 ppm 20° to 30° C
10 ppm 0° to 50° C
Ramp/Set
Ramp: increments/decrements
voltage, current, phase
angle, and frequency at
user defined ramp rates.
Ensures smooth, linear
changes in value.
Metering Functions
Dc Meter inputs
input Range:
0 to ±10V dc or 0 to
±20mA dc
accuracy: <0.003% typical <+0.05%
guaranteed
ac Sources
accuracy:
<0.02% for typical meter
loads
logic inputs as counters
Frequency:
10 kHz
pulsewidth: >175 microseconds.
Timers and Triggers
Timers
number:
8
Max Recording
Time:
<24 Hours
accuracy: ±0.0005% of reading,
±50 microseconds
Resolution: 100 microseconds
Time can be displayed as milliseconds,
seconds, or cycles
Triggers
number:
8
Boolean combination of logic inputs can be
used to define triggers
logic inputs
number:
logic inputs :
8 total
isolated inputs:
number:
2
Configurable as Voltage Sense or Contact
Sense
Voltage Sense: Up to 250 V ac or dc
open circuit
Test Voltage:
12 V dc nominal
Short circuit
Test current:
20 mA dc nominal
Response Time: 0.1 millisecond max pickup
and dropout
isolation: ±500 V peak
paired logic
inputs:
number:
3 pairs (6 total)
Configurable as Voltage Sense or Contact
Sense
Voltage Sense:
Up to 250 V ac or dc
open circuit
Test Voltage:
4 V dc nominal
Short circuit
Test current:
>50 mA dc nominal
Response Time: 0.1 millisecond max
pickup and dropout
isolation: ±500 V peak
logic outputs
number: 8
Configurable as Normally Open (NO) or
Normally Closed (NC) switches.
High-Speed Electronic Switches
number:
4
input Voltage: 250 V dc or ac
Switching
current:
0.5 A make or break,
maximum
Response
Time:
0.1 millisecond maximum
pickup and dropout
isolation: ±500 V peak
Outputs: Relays.
Relays:
4
Breaking
Capacity AC: 2000 VA with Vmax
250 V, Imax 8 A
Breaking
Capacity DC: 50 W with Vmax
300 V, Imax 8 A
Response Time: <10 millisecond max
pickup and dropout
isolation
between pairs: ±500 V peak
Variable output Battery Simulator
Range: Adjustable 6 to 300 V dc
Resolution: 0.3 V
power: 90 W, 1.5 A max
50/60 hz Ripple: <0.2% of range
accuracy
< +/- 5%
analog input Measurement (F6820 option)
Recording: 8 external analog and
digital channels
Source
Recording:
12 internal sources
Ranges: 250 mV rms, 2.5 V rms,
25 V rms, 250 mV rms
accuracy: ±0.06% typical, ±0.15%
maximum
Bandwidth: dc to 5 kHz
input impedance: 150 kΩ
Max. input
Voltage:
250 V rms/ dc
isolation: ±500 V peak channel-to-
channel
F6150 Technical Specifications
