OMNIA 6 LINE LEAKAGE TEST MODE

OPTIONS

OPT-01 (INTERNAL) 8 port high voltage and high current

switching matrix (OMNIA 4 only)

HS-8A (EXTERNAL) 8 port high voltage and high current

switching matrix

HS-16 (EXTERNAL)

16 port high voltage and high current
switching matrix with RS-232 and
GPIB interface

GENERAL SPECIFICATIONS

PLC REMOTE

Input:

Test, Reset, Interlock, Recall

CONTROL

File 1 through 10

Output: Pass, Fail, Test-in-Process

SAFETY

Built-in SmartGFI™ circuit

MEMORY

50 memories, 30 step/memory

INTERFACE

RS-232 standard or select GPIB or Printer
Port with time & date stamp.

SECURITY

Tamper proof front panel with
programmable password lockout avoids
unauthorized access to test setup programs.

GRAPHIC DISPLAY

320 x 240 Monographic LCD

ALARM VOLUME

10 ranges set by the numeric key on

SETTING

the front panel

CALIBRATION

Adjustments are made through the
front panel
Cal-Alert™ function to signal operator
when calibration is due

MECHANICAL

Bench or rack mount with tilt up front feet

DIMENSIONS

3U (WxHxD) 16.9 x 5.2 x 15.7 in.
(430 x 133 x 400 mm)

WEIGHT

51.68 lbs (23.44 kgs) varies with options

MODEL NUMBERS

OMNIA 4

4-in-1 System AC Hipot, DC Hipot,

Model 8004

Insulation Resistance and Ground Bond/
Ground Continuity tests

OMNIA 5

5-in-1 System AC Hipot, DC Hipot,

Model 8005

Insulation Resistance, Ground Bond/
Ground Continuity and Functional Run tests

OMNIA 6

6-in-1 System AC Hipot, DC Hipot,

Model 8006

Insulation Resistance, Ground Bond/
Ground Continuity, Functional Run test
and Line Leakage tests

SPECIFICATIONS & OPTIONS

DELAY & DWELL TIMER SETTINGS

DELAY TIME
SETTING

Range:

0.2 - 999.9 seconds

DWELL TIME

Range:

0.0 - 999.9 seconds

SETTING

0 = constant

DUT POWER

VOLTAGE

0 - 277 VAC Single Phase Unbalanced
(1 Hot or Line conductor and 1 Neutral)

CURRENT

15 AAC max. constant

SHORT CIRCUIT
PROTECTION

23 AAC, Response Time < 3 sec

LEAKAGE CURRENT

CURRENT DISPLAY

Range:

0.0

µA - 6,000 µA

MEASURING

A

UL544 Non Patient

DEVICE

B

UL544 Patient

C

IEC601-1, UL2601, EN60601-1

D

UL1563

E

IEC1010, UL3101, IEC950, UL1950

MD A - D components

Accuracy: Resistance

± 1%

Capacitance

± 5%

MD E components

Accuracy: Resistance

± 0.1%

Capacitance

± 1%

MD Voltage Limit

Maximum 30 V peak or 30 VDC

HI & LO-LIMIT

Range:

0 - 6000

µA (0 = OFF)

DELAY TIMER

Range:

0, 1.0 - 999.9 sec
(0 = Constant)

Accuracy:

± (0.1% + 0.1 sec)

OMNIA 5 & 6 FUNCTIONAL RUN TEST MODE

TRIP POINT SETTINGS & METERING

VOLTAGE

VOLT-HI

Range:

0.0 - 277.0 VAC

VOLT-LO

Accuracy:

± (1.5% of setting + 0.2 V)

CURRENT

AMP-HI

Range:

0.1 - 15.00 AAC

AMP-LO

Accuracy:

± (2.0% of setting + 0.02 A)

WATTS

WATT-HI

Range:

0 - 4200 W

WATT-LO

Accuracy:

± (5.0% of setting + 3 W)

POWER FACTOR

PF-HI

Range:

0.000 - 1.000

PF-LO

Accuracy:

± (8% of setting + 2 Counts)

LEAKAGE CURRENT

LEAK-HI

Range:

0.00 - 10.00 mA (0 = OFF)

LEAK-LO

Accuracy:

± (2% of setting + 0.02 mA)

Leakage current measuring resistor
MD=2 K

Ω ± 1%

TIMER DISPLAY

Range:

0.0 - 999.9 seconds

Accuracy:

± (0.1% of reading + 0.05 sec)
