2. Installation
27 018-332-C0-002 Rev. B
© 2001 TM
2.4 Smart Display Setup Menu
The Setup Menu contains the following items:
Top Line (provides additional information)
• SET UP MENU
• TO MANUAL SCROLL
• TO ADD’L INFO
Second Line (cycles through the following parameters):
Parameter Default Range
Minimum Maximum
FLOAT V/C 2.25 2.1V/Cell 2.35V/Cell
ACCEPT V/C 2.35 2.2V/Cell 2.45V/Cell
TEMP COMP 3mV/Cell/°C 0mV/Cell/°C 5mV/Cell/°C
BATT CAPACITY 100 Ah 0 Ah 1,000 Ah
SELF TEST OFF ON or OFF
TEST INHIBIT - - 7 days 7 days
TEST INTERVAL 30 days 0 days 360 days
TEST COUNTDOWN 0 days 0 days 365 days
TEST DURATION 10 minutes 5 minutes 180 minutes
FREQ RANGE 3.0 Hz 1.0 Hz 6.0 Hz
TAP SWITCH YES NO or YES
PIM OPTION YES NO or YES
OUTPUT 1 ON ON or OFF
OUTPUT 2 ON ON or OFF
OVER CURR 1 15.0 A 3.0 A 30.0 A
OVER CURR 2 15.0 A 3.0 A 30.0 A
RETRY DELAY 60 seconds 5 seconds 301 seconds
RETRY LIMIT 20 0 40
OVER CURR TOL 3 seconds 1 second 10 seconds
N+1 VALID NO NO or YES
STANDBY TIME 0 minutes 0 minutes ## minutes
STANDBY EVENTS 0 events 0 events ## events
SET DEFAULTS NO NO or YES
CODE VER 3.01
XM_ CLASS VER 3
DEVICE ADDRESS 0 0 15
SELECT LANGUAGE ENGLISH FRENCH SPANISH
