1. System Overview
© 2001
TM
22
018-332-C0-002 Rev. B
Figure 1-12; Switch 1 - Configuration Switch
21
A ÃVrÃvuÃ8HY
U hqr
IÃVrq
DpyqrÃ6QVÃvÃTrysUr
IÃVrq
21
2))
1.3 Dip Switch: Switch 1
Switch 1 is used to identify user-configurable options of the SSC. The ON position of the
switch indicates that the generator is in the system.
Position
Use
1
Activates the parallel status monitoring option that is described, in
detail, in the manual.
2
Not currently used.
3
Defines whether or not the APU (if present) is included in the self-test
sequence.
4-8
Not currently used.
