11 745-738-C0-001 Rev. A
1.0 Introduction
Alpha Technologies’ Remote Fuel Quantity Alarm system utilizes non-invasive Hall-effect sensing
modules to monitor fuel levels in Liquid Propane Gas (LPG) tanks equipped with “Remote Ready”
fuel gauge dials. The sensing modules transmit a ratiometric voltage output proportional to the liquid
volume in the cylinder. This voltage is detected and summed by the Fuel Alarm Quantity Relay circuit.
When necessary, the “Total Fuel Half Full” relay (Normally Closed or Normally Open “Form C” dry
contact) activates a Fuel Level alarm at the customer’s monitoring facility.
This document provides instructions for the following:
• Alarm Module Installation
• Gas Box Modifi cation and Wiring
• Sensor Installation and Connection
1.1.1 Parts, Tools, and Checklist
Qty Description Part Number
1 Field Retrofi t Kit, Fuel Quantity Alarm,CE-3X2 Alpha P/N 745-738-20-003
1 UNIBIT # 4 or equivalent
1 Ruler or Tape Measure
1 File (round) or deburring tool
1 Adjustable crescent wrench 10"
1 Multimeter and leads
1 7/16"
wrench
1 Gas pipe leak detector
1 AMP contact extraction tool
AMP P/N 189727-1
1 AMP contact insertion tool AMP P/N 91002-1
Inside CE-G cabinet:
1. Turn Gas tanks OFF.
2. If tanks are NOT equipped with Remote-Ready dials, remove braided gas hoses from tank valves.
3. Remove tanks, set aside.
NOTE
DO NOT perform this procedure on a system providing backup power.
NOTE
Refer to the Battery Safety Notes page in the front of this document for information regarding safe
maintenance practices when working with battery equipment.
1.1 Pre-Installation
