CHASSIS GROUND
#10-32 STUD, BOTH SIDES
020-702-20
030-835-20
030-845-20
BREAKER OUTPUTS
1/4-20 HARDWARE
ON 5/8" CENTERS
BREAKER RETURNS
1/4-20 HARDWARE
ON 5/8" CENTERS
A
A
A
010-619-20 (CXRF 48-1.2kW RECTIFIER)
UPTO 9 RECTIFIERS MAX.
018-598-20 (CXCM1 CONTROLLER)
SITE GROUND CABLE CONNECTION
3/8-16 HARDWARE ON 1" CENTERS
AC INPUT LINE CORDS
3 PL
NOTE: AC LINE CORDS NOT INCLUDED
WITH POWER SYSTEM
AC INPUT LINE CORDS
2 PL
REVISIONS
REV. DESCRIPTION DATE DRWN CHKED APPR'D
A
CORRECT POLARITY LABEL;
SWAP RECTIFIER SHELVES;
UPDATE TEMPLATE; REFER
TO ECO-10718
3/22/2011 HW ME ME
THESE DESIGNS AND SPECIFICATIONS ARE
CONFIDENTIAL, REMAIN THE PROPERTY OF
ALPHA TECHNOLOGIES LTD., AND SHALL NOT BE
COPIED OR USED WITHOUT ITS WRITTEN CONSENT
THIRD ANGLE PROJECTION
X.X [X]
X.XX [X.X]
X.XXX [X.XX]
ANGULAR:
[ 1] 0.040
UNLESS OTHERWISE SPECIFIED
DIM ARE IN INCHES [mm].
INTERPRET DIM AND TOL PER
ASME Y14.5M-1994
[ 0.5]
[ 0.25]
1
0.020
0.010
SCALE 1:1 SHEET
SIZE
B
DWG NO. REV
A
TITLE:
1
OF
2
TYPE
D2
053-691-08
CUSTOMER CONNECTION,
CXPS 48-1.2-225 A
ISSUE DATE
APPROVED
DESIGN
CHECKED
DRAWN
DATE APPROVALS
2009-10
SY
WH
MC
2009-09
2009-09
2009-10 SY
