Lieferumfang
GSM-Modul
GSM Antenne
Mehrsprachige Anleitung
Technische Daten
Frequenzbereich
900 / 1800 MHz
Antennenkabel
RG 174U
Kabellänge
ca. 290mm
Antennenstecker
MMCX (am Kabel)
Antennenbuchse
MMCX (am Modul)
Installation
Hinweis:
Ist die Alarmzentrale bereits in Betrieb setzen Sie die
Zentrale in den Errichtermodus. Beim Öffnen des Gehäuses
wird nun kein Sabotagealarm ausgelöst.
1. Entfernen Sie die beiden Schrauben am Gehäuseboden.
2. Heben Sie das Gehäuse vorsichtig von der Wand-montageplatte
ab.
Lösen Sie die Verbindung des Flachbandkabels von der
Wandmontageplatte bevor Sie das Gehäuse vollständig öffnen.
3. Lösen Sie alle vier Schrauben, die das Gehäuse der Zentrale
zusammenhalten (1).
