4 central processing unit (cpu), 5 system memory, Central processing unit (cpu) -6 – AAEON EMB-BT1 User Manual
Page 14: System memory -6
EMB-BT1
2-6
2.4
Central Processing Unit (CPU)
This motherboard comes with an Intel
®
J1900/E3845/E3825/E3815 processor.
EMB-BT1 CPU
CPU
2.5
System memory
EMB-BT1 204-pin DDR3 SO-DIMM sockets
DIMM_B1
DIMM_A1
This motherboard comes with two Double Data Rate 3 Low Voltage (DD3L) Small
Outline Dual Inline Memory Modules (SO-DIMM) socket. The figure illustrates the
location of the DDR3L DIMM socket:
NOTE: Use the SO-DIMM_A1 slot when inserting only one SO-DIMM.
