AAEON IMBA-H61A - Manual (Page 11)

2-3 Chapter 2: Motherboard information
Connectors/Jumpers/Slots Page
1. Serial port connectors (10-1 pin COMBH2, COM3~6) 21
2 COM2_V1 Ring/+5V/+12V selection (6-pin) 13
3. CPU and chassis fan connectors (4-pin CPU_FAN, 4-pin CHA_FAN) 17
4. ATX power connectors (24-pin EATXPWR, 4-pin EATX12V) 16
5. Intel ® LGA1155 CPU socket 6
6. DDR3 DIMM slots 11
7. Standby Power LEDs (SB_PWR1/2) 1
8. Clear RTC RAM (3-pin CLRTC) 12
9. Chassis intrusion connector (4-1 pin CHASSIS1) 20
10. Direct connector (2-pin DRCT1) 22
11 AT Mode selection (3-pin ATMODE) 13
12. System panel connector (10-1 pin F_PANEL) 18
13. Intel ® H61 Serial ATA 3.0Gb/s connectors (7-pin SATA3G_1~4) 19
14. USB 2.0 connectors (10-pin USB89, USB45; 5-pin USB10) 20
15. Digital I/O connector (10-pin DIO1) 21
16. LPT connector (26-1 pin LPT) 17
17. TPM connector (20-1 pin TPM1) 19
