AAEON GENE-TC05 User Manual
Page 77
S u b C o m p a c t B o a r d
G E N E - T C 0 5
Enabled Optimal
Default,
Failsafe Default
PCI Express Root Port 2 Settings
Disabled
PCI Express Root Port 3
Enabled Optimal
Default,
Failsafe Default
PCI Express Root Port 3 Settings
Extra Bus Reserved
0 Optimal
Default,
Failsafe Default
Extra Bus Reserved (0-7) for bridges behind this Root Bridge
Chapter 3 AMI BIOS Setup 3-39
