S u b C o m p a c t B o a r d G E N E - T C 0 5
IO=2E8h;
IRQ=3,4,5,6,7,9,10,11,12;
IO=2F0h;
IRQ=3,4,5,6,7,9,10,11,12;
IO=2E0h;
IRQ=3,4,5,6,7,9,10,11,12;
IO=2F8h; IRQ=3;
IO=3E8h;
IRQ=3,4,5,6,7,9,10,11,12;
IO=2E8h;
IRQ=3,4,5,6,7,9,10,11,12;
IO=2F0h;
IRQ=3,4,5,6,7,9,10,11,12;
Change Settings
(Serial Port 2)
IO=2E0h;
IRQ=3,4,5,6,7,9,10,11,12;
Select an optimal setting for Super IO device
RS232 Optimal
Default,
Failsafe
Default
RS422
Serial Port 2 Device
Type
RS485
Select RS232, RS422 or RS485
Chapter 3 AMI BIOS Setup 3-25
