S u b C o m p a c t B o a r d
G E N E - T C 0 5
Appendix C Mating Connector
C - 2
C.1 List of Mating Connectors and Cables
The table notes mating connectors and available cables.
Mating Connector
Connector
Label
Function
Vendor
Model no.
Available
Cable
Cable P/N
CN1
LVDS Inverter
Connector
JST PHR-5
Invertor
Cable
1705050153
CN4
Digital I/O
Connector
Neltron 2026B-10
N/A
N/A
CN5
COM Port 2
Connector
Molex 51021-0900
UART
Wafer
Cable
1701090150
CN6
+5Vout
Connector
N/A N/A
2 Pins For
SATA
Power
1702150155
CN7
System Fan
Connector
Catch 1190-700-03S
N/A
N/A
CN8
COM Port 3
Connector
Molex 51021-0900
UART
Wafer
Cable
1701090150
CN9
External AUX
Power and
PS_ON#
Catch 2418HJ-06
ATX
External
5VSB
Cable
External AUX
Power and
PS_ON#
CN10
LVDS
Connector
HIROSE
DF13-30DS-1.
25C
N/A N/A
CN11
COM Port 4
Connector
Molex 51021-0900
UART
Wafer
Cable
1701090150
CN12
COM Port 5
Connector
Molex 51021-0900
UART
Wafer
Cable
1701090150
CN13
COM Port 6
Connector
Molex 51021-0900
UART
Wafer
Cable
1701090150
CN14
USB Port
Connector
Molex 51021-0500
USB
Wafer
Cable
1700050207
