S u b C o m p a c t B o a r d G E N E - T C 0 5
Chapter 2 Quick Installation Guide 2-17
3 Data4+
4 Ground
5 Ground
2.28 PS/2 Keyboard and Mouse (CN15)
Pin S i g n a l P i n S i g n a l
1 Keyboard Data 2 Keyboard Clock
3 Ground 4 +5V
5 Mouse Data 6 Mouse Clock
2.29 Touch Screen I/F (CN16)
Pin 8 - w i r e S i g n a l 5 - w i r e S i g n a l 4 - w i r e S i g n a l
1 Ground Ground Ground
2 Top Excite Top UL(Y)
3 Bottom Excite Bottom UR(H)
4 Left Excite Left LL(L)
5 Right Excite Right LR(X)
6 Top Sense N/C SENSE
7 Bottom Sense N/C N/C
8 Left Sense N/C N/C
9 Right Sense N/C N/C
2.30 USB Port #3 (CN17)
P i n Signal
1 +5V Standby
2 Data3-
3 Data3+
4 Ground
