S u b C o m p a c t B o a r d G E N E - T C 0 5
Chapter 2 Quick Installation Guide 2-7
2.4 List of Jumpers
The board has a number of jumpers that allow you to configure your
system to suit your application.
The table below shows the function of each of the board's jumpers:
Label Function
JP1 LVDS Operating Voltage Selection
JP2 LVDS Inverter Voltage Selection
JP3 COM2 RI/+5/+12V
JP5 Touch Screen 4/5/8-wire Mode Selection
JP6 Auto Power Button Selection
JP7 RS-232/422/485 Selection-1
JP8 RS-232/422/485 Selection-2
2.5 List of Connectors
The board has a number of connectors that allow you to configure
your system to suit your application. The table below shows the
function of each board's connectors:
Label Function
CN1 LVDS Inverter Connector
CN2 LPC Expansion I/F
CN3 Front Panel
CN4 Digital I/O
CN5 COM Port #2
CN6 +5V Output for SATA HDD using
CN7 SYSTEM FAN
CN8 COM Port #3
CN9 +5VSB Output w/ SMBus
CN10 LVDS
