S u b C o m p a c t B o a r d G E N E - T C 0 5
1.3 Specifications
System
 Form
Factor 3.5”
 Processor
Intel
®
Atom™ E680 1.6GHz/ E620
600MHz/ E620T 600MHz (E620T is
for WiTAS2)
 System
Memory Onboard DDR2 667/800 Memory
 Chipset
Intel
®
EG20T PCH
 I/O
Chipset Nuvoton W82627DHG-P, Fintek
F81216DG
 Ethernet
Realtek RTL8211CL & Intel
®
82574L,
10/100/1000Base-TX, RJ-45 x 2
 BIOS
AMI BIOS - 4MB SPI Flash

Wake On LAN Yes
 Watchdog
Timer Generate a time-out system reset
 H/W
Monitor
Chipset
Supports power supply voltages and
temperature monitoring
 Expansion
Interface Mini Card x 2 (one include SIM slot
and USB interface), LPC
 Battery
Lithium battery
 Power
Requirement +12V
 Board
Size 5.75" x 4" (146mm x 101.6mm)
 Gross
Weight 0.4kg
 Operating
Temperature
32°F ~ 140°F (0°C ~ 60°C)
WiTAS2: -40°F ~ 185°F (-40°C ~
85°C) (TF-GENE-TC05W2-A10-01)
Chapter 1 General Information 1- 4
