S u b C o m p a c t B o a r d G E N E - T C 0 5
Chapter 2 Quick Installation Guide 2-20
2 Data1- 6 Data2-
3 Data1+ 7 Data2+
4 Ground 8 Ground
2.38 Audio Line In/Out and MIC Connector (CN25)
P i n Signal
1 MIC_L
2 MIC_R
3 Ground
4 Line IN_L
5 Line IN_R
6 Ground
7 Line OUT_L
8 Ground
9 Line OUT_R
10 +5V
2.39 DVI/CRT Display (CN26)
DVI
Pin S i g n a l P i n S i g n a l
C1 RED C2 GREEN
C3 BLUE C4 HSYNC
C5 Ground C6 N/C
1 DVI_TDC2# 2 DVI_TDC2
3 Ground 4 DDCCLK
5 DDCDATA 6 DVI_CLK
7 DVI_DATA 8 VSYNC
9 DVI_TDC1# 10 DVI_TDC1
11 Ground 12 N/C
