E-100-43 (R-9/03)
Dimensions
Model 100-43
PO Box 1325 Newport Beach CA 92659-0325 • Phone: 949-722-4800
Fax: 949-548-5441 • Web Site: cla-val.com • E-mail: [email protected]
CLA-VAL
CLA-VAL CANADA CLA-VAL EUROPE
4687 Christie Drive
Beamsville, Ontario
Canada LOR 1B4
Phone: 905-563-4963
Fax: 905-563-4040
E-Mail: [email protected] Chemin des M sanges 1
CH-1032 Romanel/
Lausanne, Switzerland
Phone: 41-21-643-15-55
Fax: 41-21-643-15-50
E-Mail: [email protected]
'COPYRIGHT CLA VAL 2002 Printed in USA Specific tions s bject to ch nge witho t notice
CLA-VAL UK
Dainton House, Goods Station Road
GB - Tunbridge Wells
Kent TN1 2 DH England
Phone: 44-1892-514-400
Fax: 44-1892-543-423
E-Mail: [email protected]
Fire Products
TM
®
Represented By:
T-2
"L"
T-1
T-1
T-2
T-1
T-1
"D"
FLOW
MAIN VALVE
Ends: Flanged ANSI B16.5 (150lb Class)
Body: Cast Steel (ASTM A216 WCB)
Tube Diaphragm: Nitrile Rubber
Barrier: Urethane
Bolts: 316 SS
Pressure: 250 psig (17.24 BAR)
Temp. Range: 32º F to 180º F
(0º C to 82.2º C)
MAIN VALVE OPTIONS
Body: Nickel Aluminum Bronze
(Alloy C95800) or
Duplex SS (Alloy 2205)
When Ordering Please Specify:
1. Catalog No. 100-43 2. Valve Size 3. Fluid Being Handled 4. Fluid Temperature Range 5. Inlet Pressure Range
6. Outlet Pressure Range 7. Maximum Differential Pressure 8. Minimum Differential Pressure 9. Maximum Flow Rate
4”, 6”, 8” Factory Mutual Approved
(with approved Pilot Components)
FLOW FACTORS
SIZE (IN)
3”
4”
6”
8”
*10”
CV (gpm)
160
340
885
1667
2424
KV
36.4
77.3
201
379
550
3
8.75
7.5
1/4
1/2
67
6
10.75
11.75
3/8
1/2
135
8
11.75
14.00
3/8
1/2
185
10
14.00
16.44
1/2
1/2
270
4
9.75
9.5
1/4
1/2
99
Valve Size (Inches)
L
D
T-1
T-2
Approx. Wt. (Lbs.)
80
222
191
1/4
1/2
30
150
273
299
3/8
1/2
61
200
299
356
3/8
1/2
84
250
356
418
1/2
1/2
123
100
248
241
1/4
1/2
45
Valve Size (mm)
L
D
T-1
T-2
Approx. Wt. (kgs.)
* Calculated
