N-X43H Strainer Mesh Information (R-4-09)
For a more detailed IOM Manual go to www.cla-val.com or contact a Cla-Val Regional Sales Office.
X43H Sizes
10 Mesh* 12 Mesh 14 Mesh
Screen Opening Open Area Screen Opening Open Area Screen Opening Open Area
Inch mm Inch mm % Ratio Inch mm % Ratio inch mm % Ratio
1 1 ⁄
2
” 40 0.078 2.000 55% 8.2 0.066 1.680 52% 8.0 0.056 1.410 50% 7.8
2” 50 0.078 2.000 55% 5.2 0.066 1.680 52% 5.0 0.056 1.410 50% 4.9
2 1 ⁄
2
” 65 0.078 2.000 55% 3.1 0.066 1.680 52% 3.0 0.056 1.410 50% 2.9
3 80 0.078 2.000 55% 3.5 0.066 1.680 52% 3.3 0.056 1.410 50% 3.3
4 100 0.078 2.000 55% 2.2 0.066 1.680 52% 2.0 0.056 1.410 50% 2.0
6 150 0.078 2.000 55% 2.0 0.066 1.680 52% 1.9 0.056 1.410 50% 1.8
8 200 0.078 2.000 55% 1.7 0.066 1.680 52% 1.6 0.056 1.410 50% 1.5
10 250 0.078 2.000 55% 2.8 0.066 1.680 52% 2.7 0.056 1.410 50% 2.6
12” 300 0.078 2.000 55% 1.9 0.066 1.680 52% 1.8 0.056 1.410 50% 1.8
14” 350 0.078 2.000 55% 1.4 0.066 1.680 52% 1.3 0.056 1.410 50% 1.3
16” 400 0.078 2.000 55% 2.0 0.066 1.680 52% 1.9 0.056 1.410 50% 1.8
20” 500 0.078 2.000 55% 2.0 0.066 1.680 52% 1.9 0.056 1.410 50% 1.8
24” 600 0.078 2.000 55% 1.4 0.066 1.680 52% 1.3 0.056 1.410 50% 1.3
Screen Opening
Mesh
Wire Diameter
Open Area Product Group
Inch mm Inch mm
0.0132 0.355 58 0.0040 0.102 59.0% Bolting
0.0130 0.330 54 0.0055 0.140 49.4% Bolting
0.0127 0.330 60 0.0040 0.102 57.8% Bolting
0.0127 0.323 58 0.0045 0.114 54.6% Bolting
0.0125 0.318 50 0.0075 0.191 39.1% Mill
0.0122 0.310 60 0.0045 0.114 53.3% Bolting
0.0121 0.307 62 0.0040 0.102 56.5% Bolting
0.0113 0.287 70 0.0030 0.076 62.4% Bolting
0.0112 0.284 66 0.0040 0.102 54.2% Bolting
0.0112 0.284 55 0.0070 0.178 37.9% Mill
WIRE MESH CHART
WIRE MESH CHART
Screen Opening
Mesh
Wire Diameter
Open Area Product Group
Inch mm Inch mm
0.0111 0.281 64 0.0045 0.114 50.7% Bolting
0.0110 0.279 50 0.0090 0.229 30.3% Market
0.0106 0.269 70 0.0037 0.094 54.9% Bolting
0.0106 0.269 66 0.0045 0.114 49.4% Bolting
0.0103 0.262 70 0.0040 0.102 51.8% Bolting
0.0102 0.259 72 0.0037 0.094 53.8% Bolting
0.0102 0.259 60 0.0065 0.165 37.5% Mill
0.0099 0.251 72 0.0040 0.102 50.7% Bolting
0.0098 0.249 74 0.0037 0.094 57.2% Bolting
0.0095 0.241 74 0.0040 0.102 49.6% Bolting
Screen Opening
Mesh
Wire Diameter
Open Area Product Group
Inch mm Inch mm
0.0095 0.241 76 0.0037 0.094 51.7% Bolting
0.0094 0.239 84 0.0025 0.063 62.4% ----
0.0092 0.234 76 0.0040 0.102 48.4% Bolting
0.0092 0.234 60 0.0075 0.191 30.3% Market
0.0091 0.231 78 0.0037 0.094 50.6% Bolting
0.0088 0.224 80 0.0037 0.094 49.6% Bolting
0.0088 0.224 78 0.0040 0.102 47.3% Bolting
0.0087 0.220 60 0.0080 0.203 27.0% Market
0.0085 0.216 80 0.0040 0.102 46.2% Bolting
0.0084 0.213 84 0.0035 0.089 49.8% Bolting
*X43H Standard Mesh
