Pump Solutions Group Neptune Series 600 dia-PUMP MODELS 610 thru 647 User Manual
Page 25
SECTION VI
PARTS LIST FOR PUMP MODEL 647
(REFER TO DRAWING NO. 6347, PAGE 24)
NOTE: N-3 PUMPS HAVE 316SS PUMP HEAD AND 316SS TRIM.
N-4 PUMPS HAVE C-20 PUMP HEAED AND C-20 TRIM.
FIG
NO.
DESCRIPTION
QTY.
PART
NO.
FIG.
NO
DESCRITPION
QTY.
PART
NO.
0101 Gearbox
1
000349
0146 “O” Ring, Relief Valve Cap
1
100200
0102 Worm Gear 144 SPM
1
003101
0166 Motor Coupling, 7/8”
1
100301
0104 Eccentric
1
000352
3206 Control Rod
1
000419
0105 Connecting Rod
1
000353
3207 Sealing Plate
1
000420
0106 Eccentric Collar
1
000354
3208 Control Rod Screw
1
000377
0107 Gear Shaft
1
000355
3209 Pump Body Side, Backup Plate
1
000421
0108 Gear Shaft Retainer
1
000356
3210 Teflon Diaphragm
1
000422
0109 Thrust Washer
1
000357
3211 Relief Valve Ball Guide
1
000423
0111 Worm 144 SPM
1
106550
3230 Pump Head Backup Plate (N3)
1
000440
0113 Bearing Retainer
1
000358
Pump Head Backup Plate (N4)
1
000441
0114 Connecting Rod Sleeve
1
000359
3232 ¼” Pipe Plug
1
100332
0115 Sealing Nut
1
000360
3233 “O” Ring, Sealing Plate
1
100092
0116 Sealing Nut Retainer
1
000361
3234 “O” Ring, Control Rod
1
100184
0117 Control Knob
1
000362
3235 5/8” Dia. Ball
1
100074
0118 Indicator Plate
1
000363
3236 Screw 5/16-18 x ¾” LG
8
100344
0119 Relief Valve Adjustment Screw
1
000364
3238 Screw 5/8-11 x 4” LG
2
100337
0120 Relief Valve Cap
1
000365
3242 “O” Ring, Valve Seat
4
100340
0121 Screw ½-20 x 1” LG
3
100293
3243 “O” Ring, Connection Ports
2
100341
0122 Dowel Pin 3/8” x 1-1/2” LG
3
100294
3244 Screw 5/8-11 x 2” LG
8
100343
0123 Spring Pin ¼” x 1-3/4” LG
1
100295
3247 Pump Body
1
003724
0124 Screw ¼-20 x 5/8” LG
4
100211
3248 Pump Head (N3)
1
003725
0125 Upper Bearing Cup
1
100296
Pump Head (N4)
1
003733
0126 Upper Bearing Cone
1
100297
3249 Piston 2.4 Dia.
1
003723
0127 Lower Bearing Cup
1
100298
3250 Suction/Discharge Port (N3)
2
003718
0128 Lower Bearing Cone
1
100299
Suction/Discharge Port (N4)
2
003728
0129 Fill Plug Dipstick
1
000366
3251 Spacer-Retainer (N3)
1
003720
0130 ½” Pipe Plug
1
100300
Spacer-Retainer (N4)
1
003730
0131 Motor Coupling
1
100098
3252 Valve Seat (N3)
4
003717
0132 Motor Coupling Key
1
100218
Valve Seat (N4)
4
003727
0133 Screw ¼-20 x 5/8” LG
4
100211
3253 Ball Retainer (N3)
2
003722
0135 Oil Seal
1
100303
Ball Retainer (N4)
2
003732
0136 Dowel Pin 5/8” x 2” LG
1
100304
3254 Stack Spacer (N3)
3
003719
0137 Spring Pin 1/8” x ¾” LG
1
100305
Stack Spacer (N4)
3
003729
0138 3/8” Lock Washer
4
100217
3255 1-1/8” Dia. Ball (N3)
4
107229
0139 Screw 3/8-16 x 1” LG
4
100216
1-1/8” Dia. Ball (N4)
4
107230
0140 Indicator Scale
1
100307
3256 Suction Spacer (N3)
1
003721
0141 Screw 5-16-18 x 1-1/4” LG
6
100205
Suction Spacer (N4)
1
003731
0142 Set Screw ¼-20 x 3/8” LG
1
100308
3257 Ball Guide & Retainer (N3)
1
003716
0143 Screw # 10-32 x 3/8” LG
2
100309
Ball Guide & Retainer (N4)
1
003726
0144 Screw ¼-20 x 5/8” LG
4
100211
0145 Relief Valve Spring
1
100310
