SECTION VI
PARTS LIST FOR PUMP MODELS 630, 635 & 637
(REFER TO DRAWING NO. 6300, PAGE 22)
NOTE:
N-3 PUMPS HAVE 316SS PUMP HEAD AND 316SS TRIM.
N-4 PUMPS HAVE C-20 PUMP HEAD AND C-20 TRIM.
FIG.
NO.
DESCRIPTION
QTY.
PART
NO.
FIG.
NO.
DESCRIPTION
QTY.
PART
NO.
0101 Gearbox
1
000349
3201 Pump Body
1
000414
0102 Worm Gear 58 SPM
1
000350
3202 Pump Head (N3)
1
000416
Worm Gear 117 SPM
1
000351
Pump Head (N4)
1
000417
Worm Gear 144 SPM
1
003101
3205 Piston
1
000418
0104 Eccentric
1
000352
3206 Control Rod
1
000419
0105 Connecting Road
1
000353
3207 Sealing Plate
1
000420
0106 Eccentric Collar
1
000354
3208 Control Rod Screw
1
000377
0107 Gear Shaft
1
000355
3209 Pump Body Side, Backup Plate
1
000421
0108 Gear Shaft Retainer
1
000356
3210 Teflon Diaphragm
1
000422
0109 Thrust washer
1
000357
3211 Relief Valve Ball Guide
1
000423
0111 Worm 58 SPM
1
100291
3212 Discharge Cap (N3)
1
000424
Worm 117 SPM
1
100292
Discharge Cap (N4)
1
000425
Worm 144 SPM
1
106550
3214 Vent Plug (N3)
1
000426
0113 Bearing Retainer
1
000358
Vent Plug (N4)
1
000427
0114 Connecting Rod Sleeve
1
000359
3216 Retainer Screen (N3)
1
000428
0115 Sealing Nut
1
000360
Retainer Screen (N4)
1
000429
0116 Sealing Nut Retainer
1
000361
3218 Anti-Siphon Spring (N3)
1
002384
0117 Control Knob
1
000362
Anti-Siphon Spring (N4)
1
002426
0118 Indicator Plate
1
000363
3220 Spacer-Retainer (N3)
1
000430
0119 Relief Valve Adjusting Screw
1
000364
Spacer-Retainer (N4)
1
000431
0120 Relief Valve Cap
1
000365
3222 Valve Seat (N3)
4
000432
0121 Screw 1/4-20 x 1'' LG
3
100293
Valve Seat (N4)
4
000433
0122 Dowel Pin 3/8'' x 1-1/2'' LG
3
100294
3224 Ball Retainer (N3)
2
100434
0123 Spring Pin 1/4'' x 1-3/4'' LG
1
100295
Ball Retainer (N4)
2
000435
0124 Screw 1/4-20 x 5/8'' LG
4
100211
3226 Stack Spacer (N3)
3
000436
0125 Upper Bearing Cup
1
100296
Stack Spacer (N4)
3
000437
0126 Upper Bearing Cone
1
100297
3228 Suction Cap (N3)
1
000438
0127 Lower Bearing Cup
1
100298
Suction Cap (N4)
1
000439
0128 Lower Bearing Cone
1
100299
3230 Pump Head Backup Plate (N3)
1
000440
0129 Fill Plug Dipstick
1
000366
Pump Head Backup Plate (N4)
1
000441
0130 1/2'' Pipe Plug
1
100300
3232 1/4'' Pipe Plug
1
100332
0131 Motor Coupling
1
100098
3233 "O" Ring, Sealing Plate
1
100092
0132 Motor Coupling Key
1
100218
3234 "O" Ring, Control Rod
1
100184
0133 Screw 1/4-20 x 5/8'' LG
4
100211
3235 5/8'' Dia. Ball
1
100074
0135 Oil Seal
1
100303
3236 Screw 5/16-18 x 3/4'' LG
8
100344
0136 Dowel Pin 5/8'' x 2'' LG
1
100304
3237 "O" Ring, Vent Plug
1
100335
0137 Spring Pin 1/8'' x 3/4'' LG
1
100305
3238 Screw 5/8-11 x 4'' LG
2
100337
0138 3/8'' Lock Washer
4
100217
3240 1'' Dia. Ball (N3)
4
100338
0139 Screw 3/8-16 x 1'' LG
4
100216
1'' Dia. Ball (N4)
4
100339
0140 Indicator Scale
1
100307
3242 "O" Ring, Valve Seat
4
100340
0141 Screw 5/16-18 x 1-1/4'' LG
6
100205
3243 "O" Ring, Valve Cap
2
100341
0142 Set Screw 1/4-20 x 3/8'' LG
1
100308
3244 Screw 5/8-11 x 2'' LG
8
100343
0143 Screw #10-32 x 3/8'' LG
2
100309
0144 Screw 1/4-20 x 5/8'' LG
4
100211
0145 Relief Valve Spring
1
100310
0146 "O"Ring, Relief Valve Cap
1
100200
