Extron Electronics VTG 200 User Guide User Manual
Page 3
Introduction to VTG 150 & VTG 200 ..................................... Chapter 1
Introduction .............................................................................. 1-1
VTG 150 Features ................................................................... 1-2
VTG 200 Features ................................................................... 1-2
Specifications .......................................................................... 1-2
Connecting the VTG Output Cables ..................................... Chapter 2
Connecting the VTG Output Cables ........................................ 2-1
15-Pin HD (VGA/XGA) Output ................................................. 2-1
15-Pin Apple/Mac II (VTG 150),
MacII/Quadra (VTG 200) Output ............................................. 2-2
9 Pin, TTL Output .................................................................... 2-2
RGB Output (BNC, Analog) ..................................................... 2-3
Composite vs. Separate H & V ........................................ 2-3
Sync on Red, Blue, or Green ........................................... 2-3
NTSC/PAL BNC Output (VTG 200 only) ................................. 2-3
13W3 Sun/SGI/IBM Output (VTG 200 only) ............................ 2-4
Adapting the VTG 150 to Other Standards ............................. 2-4
Monitors with a 13W3 Input Connector ............................ 2-4
Connecting TTL Output to an AT&T 6300 ........................ 2-5
Operating the Video Test Generator ..................................... Chapter 3
Operating the Video Test Generator ....................................... 3-1
Power On ......................................................................... 3-1
Timer LED ........................................................................ 3-1
Exit the Instructional Menu Cycle ..................................... 3-2
View the Scan Ranges ..................................................... 3-2
View the Scan Rates ........................................................ 3-2
Activate a Scan Rate ........................................................ 3-2
Change Scan Rate ........................................................... 3-3
Change Test Pattern ........................................................ 3-3
Change Test Pattern Color .............................................. 3-3
Auto-sequence the Test Patterns ..................................... 3-3
NTSC/PAL LED (VTG 200 only) ...................................... 3-3
Timer ................................................................................ 3-3
Add Sync to a Video Line ................................................. 3-4
Sync Output Selection ...................................................... 3-4
Power Off ......................................................................... 3-5
Application Information ........................................................ Chapter 4
VTG Formats ........................................................................... 4-1
Video Test Patterns ................................................................. 4-3
Setting Up Large Screen Projection Systems ......................... 4-5
Video Setup Guide .................................................................. 4-6
Monitor Applications ................................................................ 4-7
Troubleshooting ....................................................................... 4-9
Contents
Page i
