RGB 400xi xi xi xi xi Series Installation Guide
Installation, cont’d
RGB 400xi xi xi xi xi Series
A
Appendix A
Templates
Cut-out Templates
10
Rack mount .................................. No, but wall or furniture mountable
Enclosure type ............................ Metal
Enclosure dimensions — RGB 460xi,
xi, xi, xi, xi, RGB 472xi xi xi xi xi
Plate ................................... 4.5” H x 4.6” W (11.4 cm H x 11.7 cm
W) (2-gang)
Interface back enclosure . 2.7" H x 3.3" W x 1.1" D
(6.9 cm H x 8.4 cm W x 2.8 cm D)
(Depth excludes front panel connectors
and controls.)
Enclosure dimensions — RGB 464xi, xi, xi, xi, xi, RGB 474xi, xi, xi, xi, xi, RGB 468 Mxi, xi, xi, xi, xi,
RGB 478 Mxi xi xi xi xi
Plate ................................... 4.5” H x 6.4” W (3-gang)
(11.4 cm H x 16.3 cm W)
Interface back enclosure . 2.7" H x 3.3" W x 1.1" D
(6.9 cm H x 8.4 cm W x 2.8 cm D)
(Depth excludes front panel connectors
and controls.)
Enclosure dimensions — RGB 460xi xi xi xi xi Dual, RGB 468xi, xi, xi, xi, xi, RGB 478xi xi xi xi xi
Plate ................................... 4.50” H x 8.33” W (4-gang)
(11.43 cm H x 21.15 cm W)
Interface back enclosure . 2.7" H x 3.3" W x 1.1" D
(6.9 cm H x 8.4 cm W x 2.8 cm D)
(Depth excludes front panel connectors
and controls.)
Enclosure dimensions — RGB 460xi xi xi xi xi EC, RGB 472xi xi xi xi xi EC
Faceplate ........................... 3.2" H x 4.4" W (8.0 cm H x 11.2 cm W)
Interface enclosure ......... 2.7" H x 3.3" W x 1.1" D
(6.9 cm H x 8.4 cm W x 2.8 cm D)
(Depth excludes connectors and
controls.)
Enclosure dimensions — RGB 468xi xi xi xi xi EC, RGB 478xi xi xi xi xi EC
Faceplate ........................... 3.2" H x 7.7" W (8.0 cm H x 19.5 cm W)
Interface enclosure ......... 2.7" H x 3.3" W x 1.1" D
(6.9 cm H x 8.4 cm W x 2.8 cm D)
(Depth excludes connectors and
controls.)
Accessories
Wall/Junction box Part number
2-gang J-box, 2.5” deep 980084
3-gang J-box, 2.5” deep 980083
4-gang J-box, 2.5” deep 980097
