Cr
ossPoint / MA
V Matrix Switchers • Remote Contr
ol
Remote Contr
ol, cont’d
4-6
Cr
ossPoint / MA
V Matrix Switchers • Remote Contr
ol
4-7
Refer also to the
Cr
ossPoint 450 Plus / Cr
ossPoint Ultra / MA
V Plus User’
s Manual
at www
.extron.com.
Refer also to the
Cr
ossPoint 450 Plus / Cr
ossPoint Ultra / MA
V Plus User’
s Manual
at www
.extron.com.
Command
ASCII command
(host to switcher)
Response
(switcher to host)
Additional description
Audio output volume
Set the audio volume to a specific
value
X@
*
X%
V
Out
X@
•Vol
X%]
Example:
1*50v
Out01•Vol50
]
Set output 1 volume to 79%.
Increment volume
X@
+V
Out
X@
•Vol
X%]
Increase volume by 1 step.
Example:
1+V
Out01•Vol51
]
Decrement volume
X@
-V
Out
X@
•Vol
X%]
Decrease volume by 1 step.
Read output volume
X@
V
X%]
Save and recall presets
N
• If you try to recall a preset that is not saved, the matrix switcher responds with the error code
E11.
• The following characters are invalid in preset names: + - , ` @ = [ ] { } ‘ “ ; : | \ and ?.
Save current configuration as a
global preset
X^,
Spr
X^]
Command character is a comma.
Example:
9
,
Spr09
]
Save current ties as preset 9.
Recall a global preset
X^.
Rpr
X^]
Command character is a period.
Example:
5
.
Rpr05
]
Recall preset 5, which becomes the current
configuration.
Command
ASCII command
(host to switcher)
Response
(switcher to host)
Additional description
Lock (executive) modes
N
See “Setting the front panel locks (Executive modes)” on page 3-3 for more information on the
Lock modes.
Lock all front panel functions
1X
Exe1
]
Enable Lock mode 1.
Lock advanced front panel functions
2X
Exe2
]
Enable Lock mode 2.
Unlock all front panel functions
0X
Exe0
]
Enable Lock mode 0.
View lock status
X
X&]
Information requests
Information request
I
V
X*
X
X(
•A
X*
X
X(]
V
X*
X
X(
is the video matrix size.
A
X*
X
X(
is the audio matrix size.
Example:
MAV Plus 3216 HDA
I
V32X16•A32X16
]
Request part number
N
X1)]
Query controller firmware version
Q
X1!]
Example:
Q
1.23
]
The factory-installed controller firmware
version is 1.23 (sample value only).
N
X&
= Lock mode
0, 1, or 2
X*
= Inputs
Total number of inputs for this switcher
X(
= Outputs
Total number of outputs for this switcher
X1)
= Part number
See the CrossPoint 450 Plus / CrossPoint Ultra / MAV Plus User’s Manual, available on the Extron disk
or at
www.extron.com
for a complete list of part numbers.
X1!
= Firmware version number to second decimal place (x.xx)
N
X@
= Output number
01 – (maximum number of outputs for your model)
X%
= Volume
0 – 64 (1 dB/step except for 0-to-1, which is 22 dB) (default = 64 [0 dB])
X^
= Preset number
00 - 32 (00 = current configuration)
