Extron Electronics KP 6 Keypad Remote User Manual
Kp 6 keypad remote, User’s guide, Operation

User’s Guide
Extron Electronics, USA
1230 South Lewis Street
Anaheim, CA 92805
USA
714.491.1500
Fax 714.491.1517
Extron Electronics, Europe
Beeldschermweg 6C
3821 AH Amersfoort
The Netherlands
+31.33.453.4040
Fax +31.33.453.4050
Extron Electronics, Asia
135 Joo Seng Road, #04-01
PM Industrial Building
Singapore 368363
+65.6383.4400
Fax +65.6383.4664
Extron Electronics, Japan
Daisan DMJ Building 6F
3-9-1 Kudan Minami
Chiyoda-ku, Tokyo 102-0074 Japan
+81.3.3511.7655
Fax +81.3.3511.7656
www.extron.com
© 2002 Extron Electronics. All rights reserved.
Keypad Remote Controls
68-694-01 Rev. A
Printed in the USA
07 02
KP 6 Keypad Remote
Figure 3 — KP 6 application (with 5-pole captive
screw connector)
Operation
To select an input using the KP 6 Keypad Remote Control, press the
number key for the desired input.
Specifications
25 foot
cable
KP 6 Keypad
Remote Control
MSW 4V Switcher
MSW 4V SDI
POWER
1.2V
.5A MAX
INPUTS
OUTPUTS
1
2
3
4
CONTACT
1 2
3
4
A
B
Power ............................................. None required
Temperature/humidity .............. Storage -40° to +158° (-40° to +70°C)/ 10%
to 90%, non-condensing
Operating ...................................... +32° to +122° (0° to +50°C)/ 10% to 90%,
non-condensing
Enclosure type .............................. Plastic
Approvals ..................................... CE
MTBF ............................................. 30,000 hours
Warranty ....................................... 3 years parts and labor
