MTP AV Series • Reference Information

16

Frame Mounting (AAP Models)

The MTP T AV AAP transmitters can be mounted to any Extron AAP mounting frame that
accepts a double space (double height) AAP module (see “

AAP Accessories

” on page 15

for a partial list of AAP devices).

NOTE: The rear panel MTP connections will be inaccessible after installation. Make all

connections (see “

Transmitter and Receiver Throughput Connections

” on page 9)

and test the twisted pair system (apply a video source and observe that transmitted
video is correctly displayed) before installing the transmitter.
