background image

MDA 4V HD-SDI and SDI User's Guide • Introduction

MDA 4V HD-SDI and SDI User's Guide

MDA 4V HD-SDI and SDI User's Guide • Introduction

MDA 4V HD-SDI and SDI User's Guide • Part Numbers

MDA 4V HD-SDI and SDI User's Guide • Specifications

Video output

Number/signal type

MDA 4V HD-SDI ............... 4 single link SDI, HD-SDI, or 3G-SDI

digital component video

MDA 4V SDI ...................... 4 reclocked SMPTE-259M serial digital

component video

Connectors ..................................... 4 BNC female
Reclocking

MDA 4V HD-SDI ............... Automatic for 270 Mbps, 1.485 Gbps,

2.97 Gbps, or bypassed for other rates

MDA 4V SDI ...................... Automatic for 143 Mbps, 177 Mbps,

270 Mbps, or 360 Mbps

Nominal level ................................ 0.8 Vp-p
Minimum/maximum levels ........ 0.5 V to 1.0 Vp-p
Impedance ...................................... 75 ohms
Return loss

MDA 4V HD-SDI ............... <-25 dB @ 100 MHz
MDA 4V SDI ...................... <-25 dB @ 5 MHz

DC offset ......................................... ±5 mV maximum with input at 0 offset

Sync

Standards ........................................ 4f

sc

NTSC, 4f

sc

PAL, SMPTE-259M

General

External power supply ................. 100 VAC to 240 VAC, 50/60 Hz, external,

autoswitchable; to 12 VDC, 1 A, regulated

Power input requirements ........... 12 VDC, 0.4 A (max.)
Temperature/humidity ................ Storage: -40 to +158 °F (-40 to +70 °C) /

10% to 90%, noncondensing
Operating: +32 to +122 °F (0 to +50 °C) /
10% to 90%, noncondensing

Cooling ........................................... Convection, unvented
Rack mount .................................... Yes, with optional standard 1U 9.5" rack

shelf, part #60-190-01 or 60-604-01; or
with VersaTools

®

1U, 3.5” deep rack shelf,

part #60-190-20 or 60-604-20; or with the
MBB 100 Back of the Rack Mounting Kit,
part #70-367-01.
Also furniture mountable with optional
VersaTools Under Desk Mounting Kit
MBU 123, part #70-212-01.

Enclosure type ............................... Metal

Enclosure dimensions ................... 1.7" H x 4.3" W x 3.0" D

(1U high, quarter rack wide)
4.3 cm H x 10.9 cm W x 7.6 cm D
(Depth excludes connectors and knobs.)

Product weight .............................. 0.5 lbs (0.2 kg)
Shipping weight ............................ 2 lbs (1 kg)
Vibration ......................................... ISTA 1A in carton

(International Safe Transit Association)

Listings............................................ UL, CUL
Compliances ................................... CE, FCC Class A, VCCI, AS/NZS, ICES
MTBF ............................................... 30,000 hours
Warranty ......................................... 3 years parts and labor

N

All nominal levels are at ±10%.

N

Specifications are subject to change without notice.

Part Numbers

MDAs

MDA

Part number

MDA 4V HD-SDI

60-884-01

MDA 4V SDI

60-448-01

Optional accessories and cables

Accessory or cable

Part number

RSU 129 9" 1U universal rack shelf kit

60-190-01

RSB 129 9" 1U basic rack shelf

60-604-01

RSU 126 6" deep 1U universal rack shelf kit

60-190-10

RSU 126 6" deep 1U universal rack shelf

60-604-10

RSF 123 3" deep 1U VersaTools

®

rack shelf kit

60-190-20

RSB 123 3" deep 1U VersaTools rack shelf

60-604-20

MBD 129 through desk mounting kit

70-077-02

MBB 100 VersaTools back of the rack

mounting kit

70-367-01

MBU 123 VersaTools under-desk mounting

kit

70-212-01

EPS 1210 (12 V, 1A power supply)

70-055-01

RG6 BNC series cables (various lengths)

26-383-nn
