SPECIFICATIONS
IN6901
RS-232 to 6 Control Relays
IN6902
RS-232 to 17 Control Relays
RS-232 Control Input
Connector type
9-Pin D male
9 Pin D male
Control Signal
1200 Baud, No Parity, 8 Data Bits, 1 Stop Bit
Command Codes
[ ]
Output
Connector type
9-Pin D female
25- Pin D female
Relay Maximum Load
1 Amp @ 30V
Dimensions
Power
9V 500 mA DC
9V 500 mA DC
Size
Height: 0.9" Width: 3.5"
Depth: 2.75"
Height: 1" Width: 7.75"
Depth: 4.1"
Shipping Weight
1 lb.
2 lbs.
